– 37 –
Knob Index / Test
number (Displayed
on SSD, 7-segment
display, if present)
(Without SSD will be
displayed in binary
format. (See Binary
Chart)
Test Name
Description of test
If tests call for numbers to be shown it will: (Display on SSD,
7-segment display, if present.) (Without SSD will be displayed in
binary format. (See Binary Chart) Turning the cycle knob will index
to the next or prior test.
10 Pressure
Sensor
Pressing Start will start the test.
Pressure sensor test will have a time-out.
All valves will turn on.
All LEDs will blink at start of test.
Stop blinking LEDs as approximate water levels are crossed.
The approximate levels are:
2"
2- 7/8"
3- 3/4"
4- 1/4"
5"
5-1/2"Water valves shuts off at this level.
11 Recirculate
Pump
Pressing Start will toggle the recirculation pump on and off.
Test will have a (1 minute) time-out for how long recirculation pump
will be on.
The recirculation pump will turn off when the test is exited.
12 Drain
Pump
Pressing Start will toggle the drain pump on and off. Test will have
a (4 minute) time-out for how long drain pump will be on. The drain
pump will turn off when the test is exited.
13 Lid Switch Pressing Start will start the test.
When the lid is open, the Spin status LED will blink. When the lid is
closed, the Rinse status LED will blink.
14 Spin Pressing Start will start the test.
Spin test will perform child safety algorithm before it starts to spin.
(Two (2) sprays of water before locking the lid.) The lid must be
closed to start the test. If lid is open the Locked LED will blink.
When started, the mode shift to spin will occur if required and the
lid will be locked.
When mode shift is complete, the washer will begin spinning to max
spin speed for the model being tested.
Spin test will have a (4 minute) time-out.
Be sure to only run this test with an empty basket as there is no
OOB detection during this test.
The spin will stop when the test is exited. The lid will unlock once the
speed reaches 0 after the test is exited.
15 Agitate Pressing Start will start the test. Agitate test will perform child
safety algorithm before it starts to agitate. The lid must be closed to
start the test. If lid is open, the Locked LED will blink.
When started, the mode shift to agitate will occur if required.
When mode shift is complete, the washer will begin agitating.
The test will pause if the lid is opened after starting. The test will
resume on lid close if it was running when opened.
The test will stop when the test is exited.
(Continued next page)
