Parts List Use with Installation Instructions:
CFGHJKLMNPQRST
1 Icemaker XXXXXXXXXXXXXX
2 Owner’s Manual and
Installation Instructions
XXXXXXXXXXXXXX
3 Hose Clamp (black) XXXX XX XXX XX
4 Water Valve and Tube Assembly* XXXXXXXXXXXXXX
5 Adhesive-Backed Water Line Fasteners XXXXXXXXXXXXXX
6 Hose Clamp (not black) XXX XX XX
7 Hex-Head Screw for Water Line Clamp XX X XX X XX XX
8 Water Line Clamp (strain relief) XXX XXXXXXXXX
9 Warranty Label XXXXXXXXXXXXXX
10 Fill Tube Extension (3/4″ O.D.) XXX X XX
11 Ice Bucket XXXX XXXXXX
12 Water Line Clamp (strain relief) XX
13 Hex-Head Screw X XXXXX XXXXXXX
14 Phillips Head Screw (2) XX XXXXX
15 Water Tube Inlet XXXX XX XXX X
16 Fill Tube with Foil (5/8″ O.D.) XXX XX X XX X
17 Icemaker Fill Cup (side-mounted) XXXXX XXXXXXX
18 Icemaker Power Cord Adapter (4 pin) XXXXX X
19 Water Valve wire extension X
20 Wire Ties (2) XXXXXXXXXXXX
21 Insulated Fill Tube (5/8″ O.D.) X
22 Hex-Head Screw (2) X
23 Icemaker Fill Cup (center-mounted) X
24 Icemaker Insert X
25 Water Valve Wire Adapter X
26 Icemaker Bracket (on some models) X
27 Screws to Install Bracket to X
Refrigerator Wall (3)
28 Feeler Arm (Curved) X
29 Icemaker Fill Cup X
(end-mounted – 2-3/4″ long)
*Always change the water valve when replacing an icemaker that makes round cubes.
This new icemaker uses a different voltage which may cause the old valve to fail.
For dispenser models, order GE Part Number WR57X96.
