GE JVM1950 - Outside Top Exngust

Installation Instructions
This oven is designed for adaptation to the following
3 types of ventilation:
A. Outside Top Exhaust (Vertical Duct]
B. Outside Back Exhaust (Horizontal Duct]
C. Recirculating (Non-Vented Ductless}
A | OUTSIDE TOP EXHAUST
(VERTICAL DUCT)
2 [INSTALLATION TYPES (choose A, 8 or C)
NOTE: For JVM1950, PVM1970, DVM1950, and PVM2170
models. This oven is shipped assembled for Outside Top
Exhaust. Select the type of ventilation required for your
installation and proceed to that section.
NOTE: For JNM1951 and PNM1971 models. This oven is
shipped assembled for Recirculating. Select the type of
ventilation required for your installation and proceed to that
section.
gp | OUTSIDE BACK EXHAUST
(HORIZONTAL DUCT)
Adaptor in Place for
Outside Top Exhaust
See page 12
c | RECIRCULATING
(NON-VENTED DUCTLESS)
See page 15
See page 19
A
_
A Charcoal Filter Accessory Kit
is required for the non-vented
exhaust. (See your Owner’s
a Manual for the kit number.)
