GE Kilsen KFP-CF Series User Manual

8 Kilsen KFP-CF Series Operation Manual
Fault
Fault status is indicated as follows:
• General faults are indicated by the general Fault LED and the corresponding zone,
function, or device fault LED indicator flashing.
• Mains power faults and mains fuse faults are indicated by a flashing general Fault
LED and a steady Supply Fault LED.
• Battery power and battery fuse faults are indicated by a flashing general Fault
LED and a flashing Supply Fault LED.
• Earth faults are indicated by a flashing general Fault LED and a steady Earth Fault
LED.
• The internal buzzer sounds intermittently.
WARNING: Contact your installation or maintenance contractor to investigate the
cause of all reported faults.
Disabled
Disabled zones are indicated as follows:
• The general Disable LED and the corresponding zone Fault/Disable/Test LEDs are
steady.
• There is no acoustic indicator.
Disabled sounders are indicated as follows:
• The general Disable LED and the Sounder Fault/Disable/Test LEDs are steady.
• There is no acoustic indicator.
Disabled fire routing is indicated as follows:
• The general Disable LED and the Fire Routing Fault/Disable/Test LEDs are steady.
• There is no acoustic indicator.
Disabled expansion modules are indicated as follows:
• The general Disable LED and the I/O Fault/Disabled LEDs are steady.
• There is no acoustic indicator.
Test
A zone test is indicated as follows:
• The general Test and the corresponding zone Fault/Disable/Test LEDs are steady.
• There is no acoustic indicator.
A sounder test is indicated as follows:
• The general Test and the Sounder Fault/Disable/Test LEDs are steady.
• There is no acoustic indicator.
A fire routing test is indicated as follows:
• The general Test and the Fire Routing Start Fault/Disable/Test LEDs are steady.
• There is no acoustic indicator.

GE Kilsen KFP-CF Series Specifications

General

Brand	GE
Model	Kilsen KFP-CF Series
Category	Control Panel
Language	English
