Chapter 5: Technical specifications
Kilsen KFP-CF Series Installation Manual 53
Mechanical and environmental specifications
Mechanical
Cabinet dimensions (no cover)
Two- and four-zone control panels
Eight-zone control panel
300 × 97 × 402 mm
421 × 100 × 447 mm
Weight without batteries
Two- and four-zone control panels
Eight-zone control panel
2.8 kg
3.9 kg
Number of cable knockouts
Two- and four-zone control panels
Eight-zone control panel
14 x Ø 20 mm at top of cabinet
2 x Ø 20 mm at bottom of cabinet
12 x Ø 20 mm at rear of cabinet
20 x Ø 20 mm at top of cabinet
2 x Ø 20 mm at bottom of cabinet
26 x Ø 20 mm at rear of cabinet
IP rating IP30
Environmental
Operating temperature
Storage temperature
−5 to +40ºC
−5 to +70ºC
Relative humidity 10 to 95% (noncondensing)
Type class conditions 3K5 of IEC 60721-3-3
Note: For detailed cabinet drawings and dimensions, see “Cabinet drawings and
dimensions” on page 54.
