GE MEDICAL SYSTEMS LOGIQ 400/500 UNPACKING INSTRUCTIONS
REV 1 2227892
9. Lock the probe in the probe port by turning the locking handle 1/4
turn clockwise (see Image 11).
Accessories (cont'd)
10. See Image 12 and route the cable as shown.
Gel Bottle
Accessories Package
Image 11
Image 12
Locking Handle
Points Down
(Locked)
Route Cable
Route Cable
