-1-
GE MEDICAL SYSTEMS LOGIQ 400/500 UNPACKING INSTRUCTIONS
REV 1 2227892
Uncrating
LOGIQ 400/500 UNPACKING INSTRUCTIONS
1. Inspect the crate for any damage. Check shock indicator and tip
watch (see Image 1).
Image 1
Report any damage or sign of tipping to dispatcher.
2. Cut the two metal strapping bands (see Image 1).
3. Remove the top of the box.
4. On one corner of the box, you will find four quick disconnects.
NOTE: On cartons that DO NOT have quick disconnects, lift the
carton up completely above the system and remove.
Proceed to step 10.
5. On the inside of the quick disconnects is a plastic handle.
Turn the handle 1/4 turn counterclockwise (to the left).
Cut Metal Bands
