GE MEDICAL SYSTEMS LOGIQ 400/500 UNPACKING INSTRUCTIONS
REV 1 2227892
Uncrating (cont'd)
Image 2
7. Repeat this procedure for all quick disconnects.
8. Pull the corner of the box, where you removed the quick
disconnects, towards you.
9. Remove the cardboard crate.
10. Remove the plastic wrap from around the console and monitor
(see Image 3).
Image 3
6. Pull the handle of the quick disconnects so that the insert is removed
(see Image 2).
Quick
Disconnects
