GE MiCOM P142 Agile User Manual

P14xEd1
Appendix A - Ordering Options
Variants Order No.
Feeder Management P143 **
Design Suffix
CPU3 with extended memory, dual characteristic opto inputs, IEC61850, InterMICOM P
CPU3, dual characteristic opto inputs, IEC61850, InterMICOM J
Phase 2 CPU, UCA2 G
Second comms card, IEC60870 private codes, P144, improved power supply C
Expansion I/O and IDMT characteristic enhancements B
Original Release - Phase 1 A
V
x Auxiliary Rating
24-54 Vdc 7
48-125 Vdc (40-100 Vac) 8
110-250 Vdc (100-240 Vac) 9
In/Vn Rating
In = 1/5A, Vn = 100 - 120Vac 1
In = 1/5A, Vn = 380 - 480Vac (Min 196Vac Max 560Vac) 2
Hardware Options Protocol Compatibility Design Suffix Compatibility
Standard - None 1, 2, 3 & 4 All 1
IRIG-B Only (Modulated) 1, 2, 3 & 4 All 2
3 All
1, 2 & 4 J/P only
3 All
1, 2 & 4 J/P only
Ethernet (10 Mbps) 5 G, J or P * 5
Ethernet (100 Mbps) 5, 6 & 7 G or J * 6
Rear Comms 1, 2, 3 & 4 C, G, J or P 7
IRIG-B (Modulated) & Rear Comms 1, 2, 3 & 4 C, G or J 8
Ethernet (100Mbit/s) plus IRIG-B (Modulated) 5, 6 & 7 J/P * A
Ethernet (100Mbit/s) plus IRIG-B (Un-modulated) 5, 6 & 7 J/P * B
IRIG-B (Un-modulated) 1, 2, 3 & 4 J/P C
InterMiCOM + Courier Rear Port 1, 2, 3 & 4 J/P E
InterMiCOM + Courier Rear Port + IRIG-B modulated 1, 2, 3 & 4 J/P F
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Modulated IRIG-B 6, 7 & 8 J/P ** G
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Un-modulated IRIG-B 6, 7 & 8 J/P ** H
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Modulated IRIG-B 6, 7 & 8 J/P ** J
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Un-modulated IRIG-B 6, 7 & 8 J/P ** K
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Modulated IRIG-B 6, 7 & 8 J/P ** L
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Un-modulated IRIG-B 6, 7 & 8 J/P ** M
Redundant Ethernet PRP/HS
R
, 2 fibre ports + Modulated IRIG-B
6, 7 & 8 J/P *** N
Redundant Ethernet PRP/HS
R
, 2 fibre ports + Unmodulated IRIG-B
6, 7 & 8 J/P *** P
Product Specific Options
60TE Case, 16 inputs & 14 relay outputs A
60TE Case, 24 inputs & 14 relay outputs C
60TE Case, 16 inputs & 22 relay outputs D
60TE case, 24 inputs & 22 relay outputs E
60TE case, 32 inputs & 14 relay outputs F
60TE Case, 16 logic inputs & 30 relay outputs G
60TE Case, 16 inputs & 18 relay outputs (including 4 High Break) H
60TE Case, 24 inputs & 18 relay outputs (including 4 High Break) J
60TE Case, 16 inputs & 26 relay outputs (including 4 High Break) K
60TE Case, 16 inputs & 22 relay outputs (including 8 High Break) L
80TE Case, 32 inputs & 32 relay outputs M
80TE Case, 48 inputs & 16 relay outputs P
Protocol / Communications Options Hardware Compatibility Design Suffix Compatibility
1 & 2 All
7 & 8 C, G, J or P
C, E & F J/P
3 & 4 J/P
1 & 2 All
7 & 8 C, G, J or P
C, E & F J/P
3 & 4 J/P
1, 2, 3 & 4 All
7 & 8 C, G, J or P
C, E & F J/P
1 & 2 All
7 & 8 C, G, J or JP
C, E & F J/P
3 & 4 J/P
UCA2 5 & 6 G, J or P * 5
IEC 61850 over Ethernet and Courier via rear K-Bus/RS485 6, A, B, G, H , J, K, L, M, N, P J/P 6
6, A, B, G, H , J, K, L, M, N, P J/P
7
6, A, B, G, H , J, K, L, M, N, P J/P
8
* NB: UCA2 option is not available with software versions 32 and later (Design Suffix J)
Mounting Option
Flush Panel Mounting, with Harsh Environment Coating M
Rack Mounting, (80TE only) with Harsh Enviromental Coating N
Flush Panel Mounting, with harsh environment coating P
Rack Mounting, (80TE only) with harsh enviromental coating Q
Multilingual Language Option Design Suffix Compatibility
English, French, German, Spanish All 0
English, French, German, Russian G, J or P 5
English, Italian, Polish and Portuguese (Software '50' and later)
J/P 7
J/P C
Software Issue **
Settings/Customisation
Default 0
Customised A
IEC61850 over ethernet with CS103 rear port RS485 protocol
DNP3 over Ethernet with Courier rear port K-Bus/RS485 protocol
Chinese, English or French via HMI, with English or French only via Communications port
DNP3.0 4
Fibre Optic Port (ST) for SCADA Protocols (Courier,Modbus,IEC60870-5-103 or DNP3) +
IRIG-B modulated
4
* Options are not available with software versions 32 or 34 EXCEPT
for 100Mbit/s variant with IEC 61850 and software version 35 or later (Design
** Only Available with software versions 43 and later
*** Only Available with software version 46 and later
K-Bus 1
Modbus 2
IEC 60870-5-103 (VDEW) 3
Fibre Optic Port (ST) for SCADA Protocols (Courier,Modbus,IEC60870-5-103 or DNP3) 3
P14xEd1-TM-EN-1
A3
