Appendix A - Ordering Options
P14xEd1
Variants Order No.
Feeder Management P144 **
Design Suffix
CPU3 with extended memory, dual characteristic opto inputs, IEC61850, InterMICOM P
Dual characteristic opto inputs, IEC61850, InterMICOM J
Phase 2 CPU, UCA2 G
Second comms card, IEC60870 private codes, P144, improved power supply C
x Auxiliary Rating
24-54 Vdc 7
48-125 Vdc (40-100 Vac) 8
110-250 Vdc (100-240 Vac) 9
In/Vn Rating
In = 1/5A, Vn (Ph) = 100-120Vac, Vn (E/f) = 380-440Vac (Min 196Vac Max 560Vac) 4
Hardware Options Protocol Compatibility Design Suffix Compatibility
Standard - None 1, 2, 3 & 4 All 1
IRIG-B Only (Modulated) 1, 2, 3 & 4 All 2
3 All
1, 2 & 4 J/P only
3 All
1, 2 & 4 J/P only
Ethernet (10 Mbps) 5G 5
Ethernet (100 Mbps) 5, 6, 7 & 8 G, J or P * 6
Rear Comms 1, 2, 3 & 4 C, G, J or P 7
IRIG-B (Modulated) & Rear Comms 1, 2, 3 & 4 C, G, J or P 8
Ethernet (100Mbit/s) plus IRIG-B (Modulated) 6, 7 & 8 J/P A
Ethernet (100Mbit/s) plus IRIG-B (Un-modulated) 6, 7 & 8 J/P B
IRIG-B (Un-modulated) 1, 2, 3 & 4 J/P C
InterMiCOM + Courier Rear Port 1, 2, 3 & 4 J/P E
InterMiCOM + Courier Rear Port + IRIG-B modulated 1, 2, 3 & 4 J/P F
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Modulated IRIG-B 6, 7 & 8 J/P ** G
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Un-modulated IRIG-B 6, 7 & 8 J/P ** H
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Modulated IRIG-B 6, 7 & 8 J/P ** J
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Un-modulated IRIG-B 6, 7 & 8 J/P ** K
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Modulated IRIG-B 6, 7 & 8 J/P ** L
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Un-modulated IRIG-B 6, 7 & 8 J/P ** M
Redundant Ethernet PRP/HS
, 2 fibre ports + Modulated IRIG-B
6, 7 & 8 J/P *** N
Redundant Ethernet PRP/HS
, 2 fibre ports + Unmodulated IRIG-B
6, 7 & 8 J/P *** P
Product Specific Option
40TE Case, 8 inputs & 7 relay outputs A
40TE Case, 12 inputs & 11 relay outputs B
40TE Case, 16 inputs & 7 relay outputs C
40TE Case, 8 inputs & 15 relay outputs D
40TE Case, 8 inputs & 11 relay outputs (including 4 High Break) H
Protocol / Communications Options Hardware Compatibility Design Suffix Compatibility
1 & 2 All
7 & 8 C, G, J or P
C, E & F J/P
3 & 4 J/P
1 & 2 All
7 & 8 C, G, J or P
C, E & F J/P
3 & 4 J/P
1, 2, 3 & 4 All
C, E & F J/P
7 & 8 C, G, J or P
1 & 2 All
7 & 8 C, G, J or P
C, E & F J/P
3 & 4 J/P
5 & 6 G or J * 5
IEC 61850 over Ethernet and Courier via rear K-Bus/RS485 6, A, B, G, H , J, K, L, M, N, P J/P 6
6, A, B, G, H , J, K, L, M, N, P J/P
7
6, A, B, G, H , J, K, L, M, N, P J/P
8
* NB: UCA2 option is not available with software versions ≥ 32 (Design Suffix J)
Mounting Option
Flush Panel Mounting, with Harsh Environment Coating M
Flush Panel Mounting, with harsh environment coating P
Multilingual Language Option Design Suffix Compatibility
English, French, German, Spanish All 0
English, French, German, Russian G, J or P 5
English, Italian, Polish and Portuguese (Software '50' and later)
J/P 7
J/P
C
Software Issue **
Customisation
Default 0
Customised A
DNP3 over Ethernet with Courier rear port K-Bus/RS485 protocol
Chinese, English or French via HMI, with English or French only via Communications port
IEC 60870-5-103 (VDEW) 3
DNP3.0 4
UCA2
IEC61850 over ethernet with CS103 rear port RS485 protocol
Modbus 2
Fibre Optic Port (ST) for SCADA Protocols (Courier,Modbus,IEC60870-5-103 or DNP3) 3
Fibre Optic Port (ST) for SCADA Protocols (Courier,Modbus,IEC60870-5-103 or DNP3) +
IRIG-B (Modulated)
4
* Options are not available with software versions 32 or 34 EXCEPT
for 100Mbit/s variant with IEC 61850 and software version 35 or later (Design
** Only Available with software versions 43 and later
*** Only Available with software version 46 and later
K-Bus 1
A4
P14xEd1-TM-EN-1
