P14xEd1
Appendix A - Ordering Options
Variants Order No.
Directional Phase O/C and E/F with Auto-Reclose and Check Synch with Extended Function User Interface P145
** *
x Auxiliary Rating
24-54 Vdc
7
48-125 Vdc (40-100 Vac)
8
110-250 Vdc (100-240 Vac)
9
In/Vn Rating
In = 1/5A, Vn = 100 - 120Vac
1
In = 1/5A, Vn = 380 - 480Vac (Min 196Vac Max 560Vac)
2
Hardware Option
None
1
IRIG-B Only
2
Fibre Optic Port (ST) for SCADA Protocols (Courier,Modbus,IEC60870-5-103 or DNP3)
3
Fibre Optic Port (ST) for SCADA Protocols (Courier,Modbus,IEC60870-5-103 or DNP3) + IRIG-B
4
Ethernet with 10Mbps fibre optic port
5
Ethernet with 100Mbps fibre optic port
6
Courier Rear Port
7
IRIG-B (Modulated) & Courier Rear Port
8
Ethernet (100Mbit/s) plus IRIG-B (Modulated)
A
Ethernet (100Mbit/s) plus IRIG-B (Un-modulated)
B
IRIG-B (Un-modulated)
C
InterMiCOM + Courier Rear Port
E
InterMiCOM + Courier Rear Port + IRIG-B modulated
F
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Modulated IRIG-B
G
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Un-modulated IRIG-B
H
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Modulated IRIG-B
J
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Un-modulated IRIG-B
K
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Modulated IRIG-B
L
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Un-modulated IRIG-B
M
Redundant Ethernet PRP/HS
, 2 fibre ports + Modulated IRIG-B
N
Redundant Ethernet PRP/HS
, 2 fibre ports + Unmodulated IRIG-B
P
* HSR – contact Alstom for details
Product Specific Option
60TE case, 16 inputs and 16 output relays
A
60TE case, 12 inputs and 12 output relays with ANSI Symbol Terminal labelling
B
60TE case, 24 inputs and 16 output relays
C
60TE case, 16 inputs and 24 output relays
D
60TE case, 24 inputs and 24 output relays
E
60TE case, 32 inputs and 16 output relays
F
60TE case, 16 inputs and 32 output relays
G
60TE case, 16 inputs and 20 output relays (including 4 High Break)
H
60TE case, 24 inputs and 20 output relays (including 4 High Break)
J
60TE case, 16 inputs and 28 output relays (including 4 High Break)
K
60TE case, 16 inputs and 24 output relays (including 8 High Break)
L
Comms Protocol
K-Bus - (NOT with Hardware Options 5 & 6)
1
Modbus - (NOT with Hardware Options 5 & 6)
2
IEC60870 - (NOT with Hardware Options 5 & 6)
3
DNP3- (NOT with Hardware Options 5 & 6)
4
UCA2 over Ethernet and Courier via rear K-Bus/RS485 - (ONLY with Hardware Options 5 & 6) *
5
IEC 61850 over Ethernet and Courier via rear K-Bus/RS485
6
IEC61850 over ethernet with CS103 rear port RS485 protocol
7
DNP3 over Ethernet with Courier rear port K-Bus/RS485 protocol
8
* NB: UCA2 option is not available with software versions 35 & later (Design Suffix J)
Case Size / Mounting / Livery
Flush Panel Mounting, with Harsh Environment Coating
M
Flush Panel Mounting, with harsh environment coating
P
Language Option
Multilingual - English/French/German/Spanish
0
Multilingual - English/French/German/Russian
5
English, Italian, Polish and Portuguese (Software '50' and later)
7
C
* NB: Chinese etc. HMI is not available with 12 logic inputs and 12 relay outputs with ANSI Symbol Terminal labelling
Software Version
Date Dependent
**
Customisation
Default
0
Customised
A
Hardware Design Suffi
Date Dependent
*
Chinese, English or French via HMI, with English or French only via Communications port *
P14xEd1-TM-EN-1
A5
