GE HEALTHCARE OPTIMA XR200AMX/XR220AMX
D
IRECTION 5336112-1EN, REVISION 3PRE-INSTALLATION MANUAL
Chapter 6 Network / workflow information Page 35
If the Optima XR220amx system will be on a subnet, is the wireless network routed to a different
network for image viewing?
Yes No
IP addresses/names
At the facility, equipment IP addresses are:
Static Acquired via DHCP Combination of both methods
Indicate the IP address that will be assigned to the Optima XR200amx/XR220amx system, if static
addresses are used at the site. (Some DICOM-compliant devices require a fixed IP for
authentication. If dynamic addresses are assigned, authentication may not be possible.)
Optima XR200amx/XR220amx IP address: _ _ _ . _ _ _ . _ _ _ . _ _ _
The Optima XR200amx/XR220amx system uses the following IP addresses internally:
• 192.168.1.50
• 192.168.2.45
• 192.168.3.50
If the facility network uses 192.168.x.x, there will be a conflict. If this conflict occurs, contact a GE
Healthcare Service Representative to change the internal IP addresses used by the system.
The host name is the network's name for the Optima XR200amx/XR220amx system.
Optima XR200amx/XR220amx host name: _________________________
The Scheduled Station AE Title (Application Entity Title) is the name the HIS/RIS will use to send
worklist information to the Optima XR200amx/XR220amx system.
Scheduled Station AE Title: _________________________
Bandwidth/capacity
On average, images from the Optima XR220amx require 8.5 Mb per image. Be sure the network
bandwidth is sufficient.
Number of Optima XR220amx units in the facility: _____________________
Wireless network capacity
Number of access points in the area where Optima XR200amx/XR220amx will be used:
_____________
On average, access point utilization should not exceed 50% of its full capacity to support all wireless
devices. Is there sufficient RF coverage in all of the areas where Optima XR200amx/XR220amx will
be used?
Yes No
Does the network comply with QoS (Quality of Service) 802.1q?
Yes No
