28 49-3000368 Rev 0
Installation Instructions
REMOVE, REVERSE AND
REPLACE THE DOOR STRIKER
• Remove the 2 screws from the striker. Rotate the
striker 180° and reinstall the striker with its screws.
3
REMOVE THE DOOR STRIKER
ASSEMBLY AND REPLACE
ON THE OPPOSITE SIDE
(CONTINUED)
4
REVERSING THE DOOR SWING (OPTIONAL ON SOME
MODELS ONLY)
REMOVE THE DOOR STRIKER
ASSEMBLY AND REPLACE ON
THE OPPOSITE SIDE
4
• Remove the 2 screws from the striker assembly and
remove the assembly by pulling it toward the center,
pushing it up and pulling it out.
• Rotate the striker assembly and replace it on the
opposite side with its screws.
REPLACE THE DOOR HINGE
AND THE DOOR HINGE COVER
ON THE OPPOSITE SIDE
• Rotate the door hinge and replace it on the opposite
side with its screws.
• Rotate the door hinge cover and replace it on the
opposite side with its screws.
5
Hinge Cover
Hinge
To Next Page
