INSTALLATION INSTRUCTIONS
10
RE-INSTALL CONVERTIBLE
DRAWER
To reassemble doors, reverse removal steps.
Convertible drawer basket will be loose if re-installed
EDFNZDUGV/RRNIRU³)5217´HPERVVWRKHOSZLWK
re-installation.
Installation Instructions
INSTALLING THE REFRIGERATOR (Cont.)
REPLACE FREEZER DRAWER
CAUTION
Lifting Hazard
Freezer door is heavy Use both hands to secure
the door before lifting.
1. Pull the lower basket slide mechanism to full
extension with both hands.
/LIWWKHIUHH]HUGRRUDQGDOLJQWKHKRRNVZLWKWKH
notches on the slide mechanisms. NOTE: Place
one side in first, then align the other side.
3. Replace the attachment screws and torque the
screws to 65 in-lb (7.34 N-m).
11
)UHH]HUGRRU
hook and slide
mechanism notch
RE-INSTALL FREEZER BASKETS
5HLQVWDOOORZHUIUHH]HUEDVNHW
5HLQVWDOOWRSIUHH]HUGUDZHUE\SODFLQJWKH
drawer wheels onto the top of the tracks on the
VLGHRIWKHIUHH]HUZDOOV7KHIURQWZKHHOVRQWKH
IUHH]HUGUDZHUVKRXOGEHRQWRSRIWKHERWWRP
basket.
3. Check for smooth operation of baskets.
12
