INSTALLATION INSTRUCTIONS
Installation Instructions
PARTS INCLUDED
Vent Grille
Cleaning Cream
Scrub Sponge
Sheet Metal Screws (9)
(8-18 x
3
/8”)
CAUTION:
GLASS IS FRAGILE
DO NOT BUMP EDGE
OF GLASS DURING
INSTALLATION
Foam Gasket Tape
Vent Grille Gasket
Burner Grate (2)
Regulator
Blower Assembly and (4) Mounting
Nuts (10-32 keps – nuts with lock
washers attached)
Blower Plenum
Vent Filter
Burner Caps and Burner Heads
Burner Cap and
Burner Head
Burner Cap and
Burner Head
Reflective
Tape
CAUTION:
DO NOT LIFT
FROM VENT
OPENING OR
BUMP GLASS
Check to be sure that all packing materials and
tape have been removed. This will include tape on
control knobs (if applicable), adhesive tape, wire
ties, cardboard and protective plastic. Failure to
remove these materials could result in damage to
the appliance once the appliance has been turned
on and surfaces have heated.
21
7
ø8”
(21
15
ø16”SS)
20
1
ø2”
22"
2
3
ø16”
(2
1
ø4”SS)
28
3
ø4”
30" COOKTOP (DIMENSIONS FOR REFERENCE ONLY)
Unit shown fully assembled.
Unit must be vented to the outside!
29
23
ø32”
(29
13
ø16”SS)
