GE Profile J2S968 SERIES User Manual

– 49 –
Oven Sensor and Lock Switch Connector (All Gas Range without convection fan) JGSP48
OVEN SENSOR AND LOCK SWITCH CONNECTOR
1
2
3
4
5
6
7
8
OVEN TEMP SENSOR
1100Ω @ ROOM TEMP
2650Ω @ CLEAN TEMP
UNLOCK
SW. 2
LOCK
SW. 1
MEAT PROBE*
50K @ RM
CONTROL
CONNECTOR
PLUG
THERMAL
SWITCH
OPEN @275°F
CLOSES @190°F
L1
BLACK
N
L1
BAKE AND TIME BAKE
BAKE RELAY
BROIL RELAY
L1
BR
BK
L1
BLACK
N
BROIL & CLEAN UNTIL/AFTER 750˚F IS REACHED
BROIL RELAY
L1
Bake & Broil relays cannot be on at same time.
** If convection fan is not working, make the following checks:
L
1
N
CONVECTION BAKE
DBL RELAY
LOW SPEED
HI SPEED
M
CONVECTION
MOTOR
Oven Sensor and Lock Switch Connector (All Gas Range with convection fan) JGS968
1
2
3
5
7
OVEN TEMP
SENSOR 1100W @ ROOM TEMP
2650W @ CLEAN TEMP
UNLOCK
SW 2
LOCK SW 1
CONTROL
CONNECTOR
PLUG
THERMAL SWITCH
OPENS @275˚F
CLOSES @190˚F
L1
B
LACK
N
L1
BAKE AND TIME BAKE
BAKE RELAY
BROIL RELAY
L1
BR
BK
L1
BLACK
N
BROIL & CLEAN UNTIL/AFTER 750˚F IS REACHED
BROIL RELAY
L1
Bake & Broil relays cannot be on at same time.
