16 49-1000610 Rev. 0
INSTALLING THE DOOR PANEL (Cont)
,IWKHGRRUVZLQJLVJRLQJWREHFKDQJHGSOHDVHFRPSOHWHSULRUWRLQVWDOOLQJWKHGRRUSDQHO6HHSDJH
'HSHQGLQJRQWKHGRRUNLWEHLQJLQVWDOOHGWKHGRRUKDQGOHPD\QHHGWREHIOLSSHGLIWKHGRRUVZLQJLVEHLQJ
changed. Please see instructions on page 18 on how to flip the door handle.
Attaching the Door Panel
1. Remove the gasket from the inside of the door and
retain for later use.
,GHQWLI\WKHSU\WDEVRQWKHWRSDQGERWWRP
decorative door trims.
3. Pry on each tab and pull down on the trim as
shown until you can remove each of the trims.
4. Remove any plastic protective covering from the
stainless door panel
5. Place the door panel onto the outside of the door
and secure it with 6 machine screws. (Provided in
'RRU3DQHO.LW
6. Snap the upper and lower trims back on the inner
panel.
7. Re-install the door gasket.
Installation Instructions
INSTALLATION INSTRUCTIONS
1
23
4
