Page #2 background image
GE
modifications reserved Page 2/10
OPM_VCL_XXX_0K4_1K5_XGB_V012 User manual - VCL Series UPS 400-1500VA V012 - GB
User manual
Uninterruptible Power Supply
Line-interactive VCL Series UPS
400 - 600 - 800 – 1000 - 1500 VA
Please read these instructions carefully before installation and start-up of the
VCL Series UPS. Keep this manual in a safe place for future reference.
Model:
VCL Series 400 – 1500 VA
Issued by:
Product Document Department – Riazzino - CH
Date of issue:
01.07.2013
File name:
OPM_VCL_XXX_0K4_1K5_XGB_V012
Revision:
1.2
Identification No.:
Up-dating
Revision
Date
1.0
21.12.2012
1.1
22.04.2013
1.2
01-07-2013
GB

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the GE Uninterruptible Power Supply and is the answer not in the manual?

GE Uninterruptible Power Supply Specifications

VCL400

Power IconPower
rating VA/W400/250
AC input voltage window170 ~ 280Vac
frequency50 / 60 Hz auto sensing
Battery IconBattery
battery type12V, sealed lead acid, maintenance free
number x capacity of battery1x4.5Ah
battery recharge time8 hours typical
Operating Environment IconOperating Environment
ambient temperature0°C ~ 40°C (+32°F ~ 104°F)
maximum relative humidity95% (non-condensing)
storage temperature-15°C ~55°C (+5°F ~ 131°F)
Weight and Dimensions IconWeight and Dimensions
net weight4.0 kg
dimensions220x112x222 mm

VCL600

Power IconPower
rating VA/W600/360
AC input voltage window170 ~ 280Vac
frequency50 / 60 Hz auto sensing
Battery IconBattery
battery type12V, sealed lead acid, maintenance free
number x capacity of battery1x7Ah
battery recharge time8 hours typical
Operating Environment IconOperating Environment
ambient temperature0°C ~ 40°C (+32°F ~ 104°F)
maximum relative humidity95% (non-condensing)
storage temperature-15°C ~55°C (+5°F ~ 131°F)
Weight and Dimensions IconWeight and Dimensions
net weight4.6 kg

VCL800

Power IconPower
rating VA/W800/480
AC input voltage window170 ~ 280Vac
frequency50 / 60 Hz auto sensing
Battery IconBattery
battery type12V, sealed lead acid, maintenance free
number x capacity of battery1x9Ah
battery recharge time8 hours typical
Operating Environment IconOperating Environment
ambient temperature0°C ~ 40°C (+32°F ~ 104°F)
maximum relative humidity95% (non-condensing)
storage temperature-15°C ~55°C (+5°F ~ 131°F)
Weight and Dimensions IconWeight and Dimensions
net weight5.6 kg

VCL1000

Power IconPower
rating VA/W1000/600
AC input voltage window170 ~ 280Vac
frequency50 / 60 Hz auto sensing
Battery IconBattery
battery type12V, sealed lead acid, maintenance free
number x capacity of battery2x7Ah
battery recharge time8 hours typical
Operating Environment IconOperating Environment
ambient temperature0°C ~ 40°C (+32°F ~ 104°F)
maximum relative humidity95% (non-condensing)
storage temperature-15°C ~55°C (+5°F ~ 131°F)
Weight and Dimensions IconWeight and Dimensions
net weight8.4 kg

VCL1500

Power IconPower
rating VA/W1500/900
AC input voltage window170 ~ 280Vac
frequency50 / 60 Hz auto sensing
Battery IconBattery
battery type12V, sealed lead acid, maintenance free
number x capacity of battery2x9Ah
battery recharge time8 hours typical
Operating Environment IconOperating Environment
ambient temperature0°C ~ 40°C (+32°F ~ 104°F)
maximum relative humidity95% (non-condensing)
storage temperature-15°C ~55°C (+5°F ~ 131°F)
Weight and Dimensions IconWeight and Dimensions
net weight10.3 kg
