16 49-80797
INSTALLATION
Installation
STEP 4
FINALIZE INSTALLATION
1. Insert filters, see the Filters section.
2. Check operation of the lights and blower.
3. Finish the custom cabinetry.
STEP 3
RECIRCULATION KIT (If Used)
1. Cut a hole into the soffit for the exhaust duct.
2. Install the vent grill over the exhaust duct.
3. Seal the duct joints with duct tape.
Visit GEAppliances.com to order the optional recirculation kit.
Hood Center Line
Soffit Cutout
90° Angle Boot
8” to 8” ducting
Filters
6-15/16"
9-5/8"
