Tri-plane AFI
(Tri-plane AFI – cont.)
Process
1. Select tri-plane image, press Measure
2. Select AFI folder
3. Define ROI by placing 3 points following on screen prompts
Note: click for tips is available for more detailed instruction
(Tri-plane AFI – cont.)
4. Assess tracking, press Approve if ok
5. Press Select button to set AVC to event timing (already defined in
doppler) or automatic (if event timing is not defined) or scroll to set AVC
manually
Tip: Select “Next View” on touch panel
6. Repeat steps 3 and 4 to finish all 3 views
