GE Vivid E9 Quick Reference Cards

(Auto EF – cont.)
5. Select Worksheet for full results (EF, SV, Volumes, length, HR, CO, etc.)
6. You will be prompted to store loop, answer “yes” if storing loop
Note: please refer to User manual for full details on Auto EF
2D Auto EF
(Auto EF – cont.)
Auto EF Pitfalls
1. Frame Rates must be 40-80 fps
2. Heart rate limitations depending on Frame
Rate (120bpm)
3. If heart rate is too fast, tracking may not be accurate
4. Recommend to select 2 or more heart cycles or expand time before
and after heart cycle (100ms recommended)
5. Select 3 cycles on soft menu before storing or set in config when
transferring to DICOM server to avoid jumping

GE Vivid E9 Specifications

General

Power Requirements	100-240 VAC, 50/60 Hz
Display	High-resolution LCD monitor
Doppler Modes	Color Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
3D/4D Imaging	Yes
Advanced Features	Speckle Reduction Imaging
Connectivity	DICOM, USB, Ethernet
Transducer Types	Linear Array
Operating Temperature	10°C to 40°C
Humidity Range	30% to 80% non-condensing
