GE HEALTHCARE - KRETZTECHNIK VOLUSON® 730EXPERT (BT03)
D
IRECTION 105899, REVISION 3 DRAFT (APRIL 29, 2008) SERVICE MANUAL
5-46 Section 5-12 - Mechanical Descriptions
5-12-2 Monitor
• Tilt: 11° forwards and backwards
• Swivel: +/-90° rotation.
5-12-3 Top Console Positioning
5-12-4 Rotation of the Control Console
• Horizontal Access: The control panel offers 30° of horizontal adjustment to the right.
Figure 5-30 Top Console Positioning
Figure 5-31 Locking lever under Control Console
30°
Locking Lever
for locking and unlocking
the control console
