10-5-2 Functional Checks (see also Chapter 4)
The functional checks take about 60 minutes to perform. Refer to the system user documentation
whenever necessary.
10-5-2-1 System Checks
NOTE: * Some software may be considered standard depending upon system configuration.
Table 10-5 System Functional Checks
Step Item Description
1 B Mode
Verify basic B Mode (2D) operation. Check the basic system controls that affect this mode
of operation.
2 M Mode
Verify basic M Mode operation. Check the basic system controls that affect this mode of
operation.
3C Mode
Verify basic CFM Mode (Color Flow Mode) operation. Check the basic system controls that
affect this mode of operation.
4 PD Mode
Verify basic PD Mode (Power Doppler Mode) operation. Check the basic system controls
that affect this mode of operation.
5 Doppler Modes
Verify basic Doppler Mode operation (PW and CW if available). Check the basic system
controls that affect this mode of operation.
6 3D Mode
Verify basic 3D Mode operation. Check the basic system controls that affect this mode of
operation.
7
*Applicable Software
Options
Verify the basic operation of all optional modes such as Real Time 4D, RT_4D Biopsy,
VOCAL, B-Flow, XTD-View, DiagnoSTIC (Spatio-Temporal Image Correlation),
CRI (Compound Resolution Imaging), VCI (Volume Contrast Imaging), etc.
Check the basic system controls that affect each options operation.
8 Keyboard Test
Perform the Keyboard Test Procedure to verify that all keyboard controls are OK.
9 Monitor
Verify basic Monitor display functions.
10 Touch Panel
Verify basic Touch Panel display functions.
11 Measurements
Scan a gray scale phantom and use the measurement controls to verify distance and area
calculation accuracy. Refer to the Basic User Manual, Chapter 13, for measurement
accuracy specifications.
