GE WCVH4800KWW - Outer Tub Assembly

Outer Tub Assembly
• The outer tub assembly is constructed in two halves and contains
the wash basket
the
wash
basket
.
• The bearing and seal assembly is part of the outer tub rear half.
• The outer tub assembly is supported by 2 suspension springs
and 2 dampers
and
2
dampers
.
• Each spring is located between the top of the tub assembly and a
cabinet top brace, one on each side.
• Washer stabilization is achieved b
y
the use of 2 dam
p
ers that are
Copyright 2009
80
yp
located between the bottom of the tub assembly and chassis, 1 on
each side.
