GEA F5 - Table of Contents

D
GB
F
E
3
09702-09.2013-DGbF
Contents Page
1 Safety 4
1.1 Identication of safety instructions
1.2 Qualications required of personnel
1.3 General safety instructions
1.4 Additional safety instructions NH
3
1.5
Intended use
2 Product description 6
2.1 Short description
2.2 Name plate
2.3 Type code
3 Areas of application F 9
3.1 Refrigerants F, F-NH
3
3.2 Oil charge
3.3 Operating limits
4 Areas of application F-NH
3
11
4.1 Oil charge NH
3
4.2 Operating limits NH
3
5 Compressor assembly 12
5.1 Setting up
5.2 Maximum permissible inclination
5.3 Pipe connections
5.4 Pipes
5.5 Laying suction and discharge lines
5.6 Operating the shut-off valves
5.7 Operating mode of the lockable service connections
5.8 Drive
5.9 Oil sump heating (standard by F4, F5, F14 and F16)
6 Commissioning 18
6.1 Preparations for start-up
6.2 Pressure resistance test
6.3 Leak test
6.4 Evacuation
6.5 Refrigerant charge
6.6 Shaft seal
6.7 Shaft seal change
6.8 Start-up
6.9 Avoiding slugging
7 Maintenance 21
7.1 Preparation
7.2 Work to be carried out
7.3 Spare parts recommendation
7.4 Spare parts recommendation NH
3
7.5 Accessories
7.6 Excerpt from the lubricant table
7.7 Decommissioning
8 Technical data F2-F16 23
9 Technical data F2 NH
3
-F16 NH
3
24
10 Dimensions and connections F 25
11 Dimensions and connections F-NH
3
33
12 Declaration of installation 41
13 Service 42
