2 | Product description
F4, F5
Dimension and connection values can be found in Chapter 10
F5
F16
F14, F16
Fig. 2
Suction
shut-off valve
Valve plate
Base plate
Name plate
Cylinder cover
Discharge
shut-off valve
Shaft seal
Shaft end
Compressor housing
Fig. 3
Transport eyelet
Discharge shut-off valve
Cylinder cover
Compressor housing
Base plate
Valve plate
Suction
shut-off valve
Leak oil drain hose
Shaft seal
Shaft end
Transport eyelet
