GEA HGX4 R134a User Manual

D
GB
F
E
29
96179-01.2015-DGbFEI
9| Dimensions and connections
SV
DV
Suction line
Discharge line
see technical data, Chapter 8
A
Connection suction side, not lockable
1
/
8
“ NPTF
A1
Connection suction side, lockable
7
/
16
“ UNF
B
Connection discharge side, not lockable
1
/
8
“ NPTF
B1
Connection discharge side, lockable
7
/
16
“ UNF
C
Connectoin oil pressure switch OIL
7
/
16
“ UNF
D
Connection oil pressure switch LP
7
/
16
“ UNF
D1
Connection oil return from oil separator
1
/
4
“ NPTF
E
Connection oil pressure gauge
7
/
16
“ UNF
F
Oil drain M 22 x 1,5
H
Oil charge plug M 22 x 1,5
J
Oil sump heater (accessories) M 22 x 1,5
K
Sight glass -
L
Connection thermal protection thermostat
1
/
8
“ NPTF
N
Connection capacity controller M 48 x 1,5
O
Connection oil level regulator 3 x M 6
ÖV
Connection oil service valve
1
/
4
“ NPTF
P
Connection oil differential pressure sensor M 20 x 1,5
Q
Connection oil temperature sensor
1
/
8
“ NPTF

GEA HGX4 R134a Specifications

General

Brand	GEA
Model	HGX4 R134a
Category	Air Compressor
Language	English
