11c. SCQ All Units 1ph: Layout Diagram
PLAN VIEW ( 1 : 2.5 )
1
1
2
2
3
3
4
4
5
5
6
6
A A
B B
C C
D D
© [2007] ICG (UK) Limited - All Rights Reserved
"This document is protected by copyright, and the design it contains is protected by both copyright & design right, all such rights
being owned by ICG (UK) Limited. This document may also contain information which is confidential to that Company.
Neither this document nor the design or information which it contains may therefore be used, sold, licensed, transferred, copied,
lent, disclosed to any third party or otherwise be reproduced in whole or in part an any manner or form than with the prior
written consent of that Company."
IF IN DOUBT ASK
DO NOT SCALE
THIRD ANGLE
PROJECTION
TOLERANCES - UNLESS OTHERWISE STATED
Simple Assy's (max 3 Parts) ± 1.0mm
Complex Assy's (multiple Parts) ± 3.0mm
Job No.
SEE PARTS LIST
24/09/2008
Finish
Material
NATURAL
N/A
Weight
Description
Date
Checked
CUSTOMER / PROJECT NO
26/09/2008
Date
Designed By
Drawn By
B_Liu
B_Liu
Drawing / File Ref:
Issue
SCQ-6X1-XX.idw
1
Part No. / 3D Model Ref.
SCQ-621-20
Sheet Number
1 of 1
Control Assy ST1: SCQ 1ph Compressor
Sheet Size A3
PARTS LIST
ITEM PART NUMBER
DESCRIPTION BASE QTY ITEM QTY
1 200-200-708 LP SWITCH AUTO 1 1
2 200-705-015
CABLE TRUNKING: 37.5mm(H) x 25.0mm(W)
382 mm 1
3 200-708-302 AUX.CONTACT FOR P1-32 ISOLATOR 1 1
4
216-112-310 32A ISOLATOR SHAFT EXTENTION KIT
11
5
218-411-007 TERMINAL BLOCK FUSED 281-611 WAGO
11
6 218-431-305 HORIZONTAL JUMPER, WAGO 280-402
1
2
7
218-431-411 TERMINAL BLOCK BLUE 4W WAGO 280-634
1
2
8 218-431-412 TERMINAL BLOCK (EARTH)
1
2
9 218-431-439-01 TERMINAL BLOCK, WAGO 280-633 1 3
10 218-431-456 ENDPLATE FUSED TERMINAL BLOCK WAGO 1 1
11 218-431-608 TERM. END PLATE, WAGO 280-314 1 3
12 218-431-616
TERMINAL BLOCK; WAGO (249-116)
14
13 218-431-802 SLOTTED DIN RAIL - LENGTH 86.5MM 86.500 mm 3
14 218-431-802 SLOTTED DIN RAIL - LENGTH 82.5MM 82.500 mm 1
15 221-463-520
SCREW M4 x 20 HEX HEAD Stainless Steel
11
16 222-461-500 HEX FULL NUT M4x0.7 - Stainless Steel
11
PARTS LIST
ITEM PART NUMBER
DESCRIPTION BASE QTY ITEM QTY
17 222-786-601 REVERSE EXPANSION NUT 6.9mmSQ NYLON 1 3
18 223-162-613
Cross Recessed Truss Head Tapping Screw - Type AB - Type IA
12
19 224-163-509
Plain Washer:M4 (Form C) - Stainless Steel
12
20 225-382-002
Heyco Bush SB875-10
17
21 226-461-507
3/16" SS MONOBOLT 6.86mmGRIP
111
22 291-700-095
EARTH LABEL S/A
11
23 292-400-030 Spring Washer:M4 Form A - Stainless Steel
1
2
24 43-108-001 UNIVERSAL P/SWITCH MTG PLATE
11
25 44-117-A CONTROL PANEL: NS & SCQ 1 1
26 MCB SEE TABLE 1 1
27 ISOLATOR SEE TABLE 1 1
28 CONTACTORS SEE TABLE 1 1
29 DILM SIDE MNT AUX SEE TBALE 1 1
30 FAN CAPACITOR
SEE TABLE (SUPPLIED WITH FAN SET)
11
1 FIRST ISSUE FOR PRODUCTION
24/09/2008 B_Liu
REVISION HISTORY
ISSUE MODIFICATION DETAILS ECN No. DATE BY
PARTS TABLE
UNIT
CONTROLS ASSY CONTACTORS ISOLATORS FAN CAPACITOR MCB DILM SIDE MNT AUX
SCQ7-1LX-A SCQ-611-10
216-131-007 216-112-317 3uF 200-750-140
N/A
SCQ8-1LX-A SCQ-611-16
216-131-007 216-112-317 3uF 200-750-134
N/A
SCQ13-1MX-A SCQ-611-10
216-131-007 216-112-317 3uF 200-750-140
N/A
SCQ18-1MX-A SCQ-611-16
216-131-007 216-112-317 3uF 200-750-134
N/A
SCQ27-1MX-A SCQ-611-16
216-131-007 216-112-317 3uF 200-750-134
N/A
SCQ31-1MX-A SCQ-621-20
216-131-009 216-112-301 3uF 200-750-142 216-131-032
29
12
30
25
2
8
10
3
13
6
8
11
9
1321
17
18124
27
20
14
22
HAND BEND FOR CAPACITORS FITTING
12
