11d. SCQ All Units 3ph: Layout Diagram
PLAN VIEW ( 1 : 2.5 )
1
1
2
2
3
3
4
4
5
5
6
6
A A
B B
C C
D D
© [2007] ICG (UK) Limited - All Rights Reserved
"This document is protected by copyright, and the design it contains is protected by both copyright & design right, all such rights
being owned by ICG (UK) Limited. This document may also contain information which is confidential to that Company.
Neither this document nor the design or information which it contains may therefore be used, sold, licensed, transferred, copied,
lent, disclosed to any third party or otherwise be reproduced in whole or in part an any manner or form than with the prior
written consent of that Company."
IF IN DOUBT ASK
DO NOT SCALE
THIRD ANGLE
PROJECTION
TOLERANCES - UNLESS OTHERWISE STATED
Simple Assy's (max 3 Parts) ± 1.0mm
Complex Assy's (multiple Parts) ± 3.0mm
Job No.
N/A
29/09/2008
Finish
Material
NATURAL
N/A
Weight
Description
Date
Checked
CUSTOMER / PROJECT NO
26/09/2008
Date
Designed By
Drawn By
B_Liu
B_Liu
Drawing / File Ref:
Issue
SCQ-6X3-XX.idw
1
Part No. / 3D Model Ref.
SCQ-623-06
Sheet Number
1 of 1
Control Assy: SCQ 3ph Compressor
Sheet Size A3
PARTS LIST
ITEM PART NUMBER
DESCRIPTION BASE QTY ITEM QTY
1
200-200-708 LP SWITCH AUTO
11
2 200-200-739 MOTOR STARTER O'LOAD 3PH 4.0 - 6.3
11
3 200-200-744 AUX CONTACT 1 NO/1 NC NHI11-PKZ0 1 1
4
200-705-015 CABLE TRUNKING: 37.5mm(H) x 25.0mm(W) 382 mm
1
5
200-708-302
AUX.CONTACT FOR P1-32 ISOLATOR 1 1
6 216-112-301
ISOLATOR P1-32/V/SVB KLOCKNER
11
7 216-112-310 32A ISOLATOR SHAFT EXTENTION KIT 1 1
8 216-131-003 CONTACTOR DILM 9 AMPS 240V COIL N-C 1 1
10 216-210-625 20mm 3.15A ANTI SURGE GLASS FUSE 1 1
11 218-411-007 TERMINAL BLOCK FUSED 281-611 WAGO 1 1
12 218-431-305 HORIZONTAL JUMPER, WAGO 280-402
1
2
13 218-431-411 TERMINAL BLOCK BLUE 4W WAGO 280-634
1
2
14
218-431-412
TERMINAL BLOCK (EARTH)
1
2
15
218-431-439-01 TERMINAL BLOCK, WAGO 280-633
1
3
16 218-431-456 ENDPLATE FUSED TERMINAL BLOCK WAGO
11
17
218-431-608 TERM. END PLATE, WAGO 280-314
1
3
PARTS LIST
ITEM PART NUMBER
DESCRIPTION BASE QTY ITEM QTY
18 218-431-616 TERMINAL BLOCK; WAGO (249-116)
1
2
19 218-431-616 TERMINAL BLOCK; WAGO (249-116)
14
20 218-431-802 SLOTTED DIN RAIL - LENGTH 86.5MM 86.500 mm 3
21 218-431-802 SLOTTED DIN RAIL - LENGTH 82.5MM 82.500 mm
1
22 221-463-520
SCREW M4 x 20 HEX HEAD Stainless Steel
11
23 222-461-500
HEX FULL NUT M4x0.7 - Stainless Steel
11
24 222-786-601 REVERSE EXPANSION NUT 6.9mmSQ NYLON 1 3
25 223-162-613
Cross Recessed Truss Head Tapping Screw - Type AB - Type IA
12
26 224-163-509
Plain Washer:M4 (Form C) - Stainless Steel
12
27 225-382-002 Heyco Bush SB875-10 1
7
28 226-461-507 3/16" SS MONOBOLT 6.86mmGRIP
111
29 291-700-095
EARTH LABEL S/A
11
30 292-400-030
Spring Washer:M4 Form A - Stainless Steel
1
2
31 43-108-001
UNIVERSAL P/SWITCH MTG PLATE
11
32
44-117-A
CONTROL PANEL: NS & SCQ
11
33 Fan Capacitor 3uF (SUPPLED WITH FAN SET)
11
1 FIRST ISSUE FOR PRODUCTION
29/09/2008 B_Liu
REVISION HISTORY
ISSUE MODIFICATION DETAILS ECN No. DATE BY
3218
20
4
25
33 12
15
32
17
286
16
5
24
27
31
19 13
14
1
8
21
29
13
