Gecko in.xm2 User Manual

Note: This low level configuration table is valid for the sofware #181 revision 3. This information is
displayed on top side keypad at spa pack power-up. Software number is displayed first (ex: ,
, ), followed by revision (ex: ). For in.k600™ (menu-driven interface), you will find
the information in Info sub-menu located in Options menu.
8
Config #. Pump 1 Pump 2 Pump 3 Pump 4 Pump 5 BL TV lifter Sanitation Circ. Pump
Heat with
P1 or CP?
Filtration/Ozone with
P1 or CP?
1 2sp
_ _ _ _ _ _ _ _
P1 P1
2 2sp
_ _ _ _ _ _ _
x CP CP
3 2sp 2sp
_ _ _ _ _ _ _
P1 P1
4 2sp 2sp
_ _ _ _ _ _
x CP CP
5 2sp 2sp
_ _ _
x
_ _ _
P1 P1
6 2sp 2sp
_ _ _
x
_ _
x CP CP
7 2sp 2sp x
_ _ _ _ _ _
P1 P1
8 2sp 2sp x
_ _ _ _ _
x CP CP
9 2sp 2sp x
_ _
x
_ _ _
P1 P1
10 2sp 2sp x
_ _
x
_ _
x CP CP
11 2sp 2sp x
_ _ _ _ _ _
P1 P1
12 2sp
_ _ _ _
x
_ _ _
P1 P1
13 2sp
_ _ _ _
x
_ _
x CP CP
14 1sp 1sp
_ _ _ _ _ _
x CP CP
15 1sp 1sp
_ _ _
x
_ _
x CP CP
16 1sp 2sp x
_ _ _ _ _
x CP CP
17 1sp 2sp x
_ _
x
_ _
x CP CP
18 2sp 1sp
_ _ _ _ _ _ _
P1 P1
19 2sp 1sp
_ _ _
x
_ _ _
P1 P1
20 2sp 2sp x
_ _ _ _ _ _
P1 P1
21 2sp 1sp x
_ _
x
_ _ _
P1 P1
22 2sp 1sp
_ _ _ _ _ _
x CP CP
23 2sp 1sp
_ _ _
x
_ _
x CP CP
24 2sp 2sp x
_ _ _ _ _
x CP CP
25 2sp 2sp x
_ _
x
_ _
x CP CP
26 1sp 2sp x
_ _ _ _ _
x CP CP
27 1sp 2sp x x
_ _ _ _
x CP CP
28 1sp 2sp x x x
_ _ _
x CP CP
29 VSP 2sp VSP
_ _ _
x x
_
P1 P1
30 VSP 2sp
_ _ _ _
x x
_
P1 P1
31 VSP
_
VSP
_ _ _
x x
_
P1 P1
9919-101177-D Rev. 07-2016
© Groupe Gecko Alliance Inc., 2016
All trademarks or registered trademarks are the property of their respective owners.
www.geckoalliance.com
Configuration selection chart
Software #181, rev. 3.00
Glossary
P1 Pump 1
CP Circulation Pump
VSP VSP Pump
1sp 1 speed pump
2sp 2 speeds pump
X Installed
For complete TechBook or more information, see our website: www.geckoalliance.com
