Page 4 Revision I FROM 2012-09-20
Operating voltage - 230V +10% -15%
Operating temperatures - +5°C to +40°C
Humidity - 20% to 80% RH
Ingress protection - IP65 at the front of the control panel
Table 1: Designation of relays and output loads
Note !!!
Currents as specified in the Table are currents consumed by particular
equipment during normal operation and include starting currents of
this equipment !!!
The aggregate current consumed simultaneously may not exceed 10A !!!
III. ORDERING INFORMATION
When ordering, specify the full name of the controller, according to the designation described in chapter
II. Pay special attention to the following:
1. Enclosure type: 02 – minipanel, 03 – large keyboard
2. Specify the need for the light key: L – installed, 0 – not installed
3. Option for buzzer installation: B – installed, 0 – not installed
4. Relays you need to be installed 1 2 3 4
5. Option for door sensor connector installation:
D – connector for mechanical or magnetic door sensor,
Y – connector for optical door sensor,
0 – no door sensor installed.
Additionally, specify the following:
1. Length of the ribbon cable connecting the actuator module and the keyboard panel.
2. Length of temperature sensors.
You can also order additional door opening sensors operating in an entirely touchless manner:
a. magnetic sensor with range of 1-2 cm,
b. optical sensor with range of 1-2 cm.
