GeekTale K02 - Installing Latch and Strike Plate

Strike parts Single latch
2 "
3
4
/
(70mm)
2 "
3
8
/
(60mm)
or
INSTALLING LATCH AND
STRIKE PLATE
1. Install latch into the door, make sure latch fits inside the door opening.
2. Install the strike into the door frame, make sure the latch can go into the
strike smoothly.
2 "
3
4
/
2 "
3
4
/
-
2 "
3
8
/
Screws A
If your door’s backset is
(70mm), pull-out the face
plate to extend.
60 OR 70MM
Angle faces jamb
