PANEL DESCRIPTIONS
3
LED Indicators for the
eight sources
IR Eye
HDMI
Input 1
5v Power
HDMI
Input 2
RS-232
Port
HDMI
Input 3
HDMI
Out
HDMI
Input 4
HDMI
Input 5
HDMI
Input 6
HDMI
Input 7
HDMI
Input 8
IR Extender
Port
