InP.1 Setting Input 1
This menu lets you configure parameters for the input 1 signals
Probe type, signal, enable custom linearization, and main input scale.
Probe type Scale limits
0 Input disabled
1 TC J °C 0/1000
2 TC J °F 32/1832
3 TC K °C 0/1300
4 TC K °F 32/2372
5 TC R °C 0/1750
6 TC R °F 32/3182
7 TC S °C 0/1750
8 TC S °F 32/3182
9 TC T °C -200/400
10 TC T °F -328/752
11 PT100 °C -200/850
12 PT100 °F -328/1562
Probe type Scale limits
13 Potentiometer≥100Ω -19999/99999
with 2.5V power supply
14 Strain gauge -19999/99999
positive polarization
sensitivity: 1.5 ... 4mV/V
15 Strain gauge -19999/99999
symmetrical polarization
sensitivity: 1.5 ... 4mV/V
16 60mV -19999/99999
17 ±60mV -19999/99999
18 100mV -19999/99999
19 ±100mV -19999/99999
20 1V -19999/99999
21 ±1V -19999/99999
22 5V -19999/99999
23 ±5V -19999/99999
24 10V -19999/99999
25 ±10V -19999/99999
26 0...20 mA -19999/99999
27 4...20 mA -19999/99999
28 Strain-gauge positive -19999/99999
polarization calibrated 40mV
29 Strain-gauge symmetrical -19999/99999
polarization calibrated 40mV
30 Strain-gauge positive -19999/99999
polarization calibrated 60mV
31 Strain-gauge symmetrical -19999/99999
polarization calibrated 60mV
SV
F
PV
SV
F
PV
Input 1 Digital Filter
[0.00 ... 20.00] sec
SV
F
PV
InP.1
tyP.1
F1t.1
SV
F
PV
Decimal Point Position for Scale
Input 1
dPS.1
SV
F
PV
MIN Scale Limit Input 1
SV
F
PV
MAX Scale Limit Input 1
LoS.1
x1S.1
SV
F
PV
Offset Correction Input 1
[-999 ... +999] scale points
0FS.1
SV
F
PV
Offset Input 1
[-9.999 ... +9.999] mV
SG0F.1
SV
F
PV
Sensitivity Input 1
[-0.000 ... +9.999] mV/V
SGSE.1
Only for probe type 28, 29, 30, 31
Note
- For input type 27 (4...20mA), a current below 2mA causes the
Err and activates the assigned relay state specified with parame-
ter -rEL.
- The type 28, 29, 30, 31 input can be used without having to cali-
brate the probe. Simply enter the Offset and Sensitivity data reque-
sted in configuration (ex.: 0.193mV; 1.985mV/V).
- For types 28, 29 Maximum sensitivity is 4mV/V with 10V power
supply.
- For types 30, 31 Maximum sensitivity is 6mV/V with 10V power
supply.
If set to “0” the average filter is excluded on the sampled
value
+32 with custom linearization
+64 only for cold junction compensation thermocouples
Size
0 xxxxx
1 xxxx.x
2 xxx.xx (*)
3 xx.xxx (*)
4 x.xxxx (*)
(*) Not available for TC, RTD
probes
+8 disables the Lo and x1 messages for linear inputs only
+16 disables the Ebr message
+32 for differential linear inputs probe type 16...25
+64 disables the E.CAL.1 message
Min...Max value assigned to input selected with
parameter TYP1
[LoS.1 must be always < than xiS.1]
