Display Default CONF Description
Pb.4 100.0 Proportional band, group 4
It.4 4.0 Integral time, group 4
dt.4 0.0 Derivative time, group 4
PrS.4 0.0 Reset power, group 4
UAL.4 400 Activation setpoint group 4
Pb.5 100.0 Proportional band, group 5
It.5 4.0 Integral time, group 5
dt.5 0.0 Derivative time, group 5
PrS.5 0.0 Reset power, group 5
UAL.5 500 Activation setpoint group 5
Pb.6 100.0 Proportional band, group 6
It.6 4.0 Integral time, group 6
dt.6 0.0 Derivative time, group 6
PrS.6 0.0 Reset power, group 6
UAL.6 600 Activation setpoint group 6
Pb.7 100.0 Proportional band, group 7
It.7 4.0 Integral time, group 7
dt.7 0.0 Derivative time, group 7
PrS.7 0.0 Reset power, group 7
UAL.7 700 Activation setpoint group 7
Pb.8 100.0 Proportional band, group 8
It.8 4.0 Integral time, group 8
dt.8 0.0 Derivative time, group 8
PrS.8 0.0 Reset power, group 8
UAL.8 800 Activation setpoint group 8
Lo.P 0.0 MIN power limit
xi.P 100.0 MAX power limit
(.0E 0 Type of cooling
c.SP 0.0 Deviation cooling setpoint
rSt 0 Manual Reset
A.rs 0 Antireset
FFd 0.0 Feed Forward
Pr.dt 0 Process dead time
Pr.GA 0.0 Process gain
Pr.t1 0.0 Main process time constant
db 0 Dead band
SoF 0.0 Softstart time
Lb.t 30.0 LBA alarm trip time
Lb.P 25.0 Power limit in LBA alarm state
A0.P 0.0 Manual power at power-on or Auto/Man
FA.P 0.0 Fault Action Power
G.SP 0.0 Setpoint gradient
G.S2 0.0 Setpoint 2 gradient
G.0vt 0.0 Control output gradient
St.vd 0.1 Delta of power inc/dec from keys or digital inputs
Menu (FG
SP.r 2 Remote setpoint type
LoSP 0 Lower setpoint limit
xiSP 3500 Upper setpoint limit
0.A.r 0 Definition manual remote
0.A.t 0 Switching mode Man/Auto control
A.0.t 0 Switching mode Auto/Man control
L.r.t 0 Switching mode local/remote setpoint
P.0n.t 0 Power-on mode
Menu SEr
(od 1 Instrument code
bAv 4 Serial communication baudrate
Par 0 Serial communication parity
Menu INP1
typ.1 14 Type of probe or signal for input IN1
Fit.1 0.1 Digital filter input IN1
dPS.1 0 Decimal point position for IN1
LoS.1 0 Min. scale limit input IN1
xiS.1 3500 Max. scale limit input IN1
0fS.1 0.0 Offset input IN1
SG0F.1 0.000 Offset input IN1 calibrated 40mV
SGSE.1 4.000 Sensitivity input IN1 calibrated 40mV
Menu INP2
typ.2 0 Type of probe or signal for input IN2
