AVR function
Range
0:AVR function enable
1
:AVR function disable
2
:AVR function disable for stop
3
:AVR function disable for Deceleration
4
:
AVR function disabled for stop & Deceleration from one speed to
another speed.
5
:when VDC>(360V/740V), AVR function is disabled for stop and
Deceleration
Automatic voltage regulator function provides a level of output voltage stability when there is
input voltage instability. So when 08-08=0, Input voltage fluctuations will not effect the output
voltage.
08-08=1. Input voltage fluctuations will cause fluctuations on output voltage.
08-08=2. AVR is disabled during stopping to avoid an increase in stopping time.
08-08=3. AVR is disabled only during deceleration from one speed to another speed. This will
avoid longer than required deceleration time.
08-08=4, AVR function disabled for stop & Deceleration from one speed to another speed.
08-08=5, When VDC>360(200V series) or VDC>740V(400V series), AVR function is disabled
for stop and deceleration.
08- 09
Input phase loss protection
Range
0
:Disabled
1
:Enabled
When 08-09=1:On phase loss warring message PF is displayed.
08- 10
PTC Motor Overheat Function
Range
0
:
Disable
1: Decelerate to stop
2:
Coast to stop
3: Continue running, when warning level is reached.
Coast to stop, when protection level is reached.
08- 11
PTC Signal Smoothing Time
Range
0.00 ~ 10.00s
08- 12
PTC Detection Time Delay
Range
1 ~ 300s
08- 13
PTC Protection Level
Range
0.1 ~ 10.0
V
08- 14
PTC Detection Level Reset
Range
0.1 ~ 10.0V
08- 15
PTC Warning Level
Range
0.1 ~ 10.0V
Selection for motor overheat protection:
PTC (Positive temperature coefficient) sensors are used in motor windings to provide additional
motor protection from overheat.
PTC thermistor can be connected to terminals AVI and AGND.
A voltage divider resistor R is necessary to be connected as shown below in figure (b).
1) PTC Over Temperature Detection: If 08-10 =1 (Decelerate to stop) or 2 ( Cost to stop).
Over temperature is detected by PTC input at terminal AVI.
