gefran VDI100 User Manual

Function Register No Function Register No Function Register No
Group 5 Group 5 Group 6
5 – 25 0519H 6 – 25 0619H
5 – 26 051AH 6 – 26 061AH
5 – 27 051BH 6 – 27 061BH
5 – 28 051CH 6 – 28 061CH
5 – 29 051DH 6 – 29 061DH
5 – 30 051EH 6 – 30 061EH
5 – 31 051FH 6 – 31 061FH
5 – 32 0520H 6 – 32 0620H
Function Register No Function Register No Function Register No Function Register No
Group 6 Group 7 Group8 Group 8
6 – 33 0621H 7– 00 0700H 8– 00 0800H 8 – 41 0829H
6 – 34 0622H 7 – 01 0701H 8 – 01 0801H 8 – 42 082AH
6 – 35 0623H 7 – 02 0702H 8 – 02 0802H 8 – 43 082BH
6 – 36 0624H 7 – 03 0703H 8 – 03 0803H 8 – 44 082CH
6 – 37 0625H 7 – 04 0704H 8 – 04 0804H
6 – 38 0626H 7 – 05 0705H 8 – 05 0805H
6 – 39 0627H 7 – 06 0706H 8 – 06 0806H
6 – 40 0628H 7 – 07 0707H 8 – 07 0807H
6 – 41 0629H 7 – 08 0708H 8 – 08 0808H
6 – 42 062AH 7 – 09 0709H 8 – 09 0809H
6 – 43 062BH 7 – 10 070AH 8 – 10 080AH
6 – 44 062CH 7 – 11 070BH 8 – 11 080BH
6 – 45 062DH 7 – 12 070CH 8 – 12 080CH
6 – 46 062EH 7 – 13 070DH 8 – 13 080DH
6 – 47 062FH 7 – 14 070EH 8 – 14 080EH
7 – 15 070FH 8 – 15 080FH
7 – 16 0710H 8 – 16 0810H
7 – 17 0711H 8 – 17 0811H
7 – 18 0712H 8 – 18 0812H
7 – 19 0713H 8 – 19 0813H
7 – 20 0714H 8 – 20 0814H
7 – 21 0715H 8 – 21 0815H
7 – 22 0716H 8 – 22 0816H
7 – 23 0717H 8 – 23 0817H
7 – 24 0718H 8 – 24 0818H
7 – 25 0719H 8 – 25 0819H
7 – 26 071AH 8 – 26 081AH
7 – 27 071BH 8 – 27 081BH
7 – 28 071CH 8 – 28 081CH
7 – 29 071DH 8 – 29 081DH
7 – 30 071EH 8 – 30 081EH
7 – 31 071FH 8 – 31 081FH
7 – 32 0720H 8 – 32 0820H
7 – 33 0721H 8 – 33 0821H
8 – 34 0822H
8 – 35 0823H
8 – 36 0824H
8 – 37 0825H
8 – 38 0826H
8 – 39 0827H
8 – 40 0828H
Function Register No Function Register No Function Register No
Group 9 Group 10 Group 11
9– 00 0900H 10– 00 0A00H 11– 00 0B00H
9 – 01 0901H 10 – 01 0A01H 11 – 01 0B01H
9 – 02 0902H 10 – 02 0A02H 11 – 02 0B02H
16 VDI100 • Instruction manual
