1.1.2. Register and Data Format
Command Data (Read / Write)
Register No. Bit Content
2500H
Reserved
Operation Signal
0 Operation Command 1 : Run 0 : Stop
1 Reverse Command 1 : Reverse 0 : Forward
2 External Fault 1 : Fault
3 Fault Reset 1 : Reset
4 Reserved
5 Reserved
6 Multi-function Comm S1 1 :“ON”
7 Multi-function Comm S2 1 :“ON”
8 Multi-function Comm S3 1 :“ON”
9 Multi-function Comm S4 1 :“ON”
A Multi-function Comm S5 1 :“ON”
B Multi-function Comm S6 1 :“ON”
C Multi-function Comm S7 1 :“ON”
D Multi-function Comm S8 1 :“ON”
E Inverter mode 1 : “ON”
F Torque Command set by Communication 1: “ON”
2502H *Frequency Command (Unit: 0.01Hz)
2503H Torque Command (+/-8192 corresponding to the rated torque +/-100%)
2504H Speed limit (+/- 120 corresponding +/-120%)
2505H AO1 (0.00V ~ 10.00V)
2506H
AO2 (0 ~ 1000): Voltage (corresponding to 0.00~10.00V); Current
( corresponding to 4mA~20mA)
2507H DO
2508H Reserved
2509H Reserved
250AH Reserved
250BH Reserved
250CH Reserved
250DH Reserved
250EH Reserved
250FH Reserved
2510H G12-00 H-WORD
2511H G12-00 L-WORD
Note: Write in zero for Not used BIT, do not write in data for the reserved register.
** If the maximum output frequency of motor is over 300HZ,the frequency resolution is changed to 0.1Hz
Monitor Data (Read-only)
Register No. Bit Content
2520H
Operation Signal
0 Operation 1 : Run 0 : Stop
1 Direction 1 : Reverse 0 : Forward
2 Inverter ready 1 : ready 0 : unready
3 Fault 1 : Abnormal
4 Warning 1 :“ON”
5 Zero Speed 1 :“ON”
6 Is440V 1 :“ON”
7 Frequency Agree 1 :“ON”
8 Set Frequency Agree 1 :“ON”
9 Frequency Detection 1 1 :“ON”
A Frequency Detection 2 1 :“ON”
B Under Voltage 1 :“ON”
C Baseblock 1 :“ON”
D Freq Ref. not from Comm. 1 :“ON”
E Seq. not from Comm. 1 :“ON”
F Over Torque 1 :“ON”
8 VDI100 • Instruction manual
