gefran VDI100 User Manual

Register No. Bit Content
2521H
Error Description
0 30
1 UV 31
2 OC 32
3 OV 33
4 OH1 34
5 OL1 35
6 OL2 36
7 OT 37
8 UT 38 CF07
9 SC 39
10 Ground OC 40
11 Fuse broken 41 OLDOP
12 Input Phase Loss 42
13 Output Phase Loss 43
14 PG Overspeed 44
15 PG Open 45
16 PG Speed Deviation 46
17 External Fault 01 47 SS1
18 External Fault 02 48 CF20
19 External Fault 03 49 RUN
20 External Fault 04 50
21 External Fault 05 51
22 External Fault 06 52
23 External Fault 07 53
24 External Fault 08 54
25 FB 55
26 OPR 56
27 57
28 CE 58
29 STO 59
30 Over Torque 2 61
2522H
DI State
0 Terminal S1
1 Terminal S2
2 Terminal S3
3 Terminal S4
4 Terminal S5
5 Terminal S6
6 Terminal S7
7 Terminal S8
8 Reserved
9 Reserved
A Reserved
B Reserved
C Reserved
D Reserved
E Reserved
F Reserved
2523H Frequency command (0.01Hz)
2524H Output frequency (0.01Hz)
2525H Reserved
2526H DC voltage command (0.1V)
2527H Output current (0.1A)
VDI100 • Instruction manual 9
