Load Diagrams
503Z Load Diagram - Standard Dipper Arm Maximum Permissible Loads
All table values are in lbs. (kg) and for a machine in a horizontal position on
firm ground without bucket.
If equipped with a bucket or other implements, lift capacity or tilt load is
reduced by bucket or implement weight.
Calculation basis: According to ISO 10567.
The excavator's lift capacity is restricted by the settings of the pressure relief
valves and the hydraulic system's stabilizing features.
Neither 75% of the static tilt load nor 87% of the hydraulic lift capacity is
exceeded.
0'0"
(0.0 m)
3'3"
(1.0 m)
6'6"
(2.0 m)
9'9"
(3.0 m)
13'0"
(4.0 m)
16'3"
(5.0 m)
0'0"
(0.0 m)
3'3"
(1.0 m)
6'6"
(2.0 m)
9'9"
(3.0 m)
13'0"
(4.0 m)
16'3"
(5.0 m)
3'3"
(1.0 m)
6'6"
(2.0 m)
9'9"
(3.0 m)
13'0"
(4.0 m)
-13'0"
(-4.0 m)
16'3"
(5.0 m)
-3'3"
(-1.0 m)
-6'6"
(-2.0 m)
-9'9"
(-3.0 m)
0'0"
(0.0 m)
13’0”
(4.0 m)
9’9”
(3.0 m)
6’6”
(2.0 m)
13’0”
(4.0 m)
2,337*
(1060*)
1,786
(810)
9’9”
(3.0 m)
2,260*
(1025*)
1,290
(585)
2,227*
(1010*)
1,720
(780)
6’6”
(2.0 m)
2,304*
(1045*)
1,080
(490)
2,612*
(1185*)
1,609
(730)
3,483*
(1580*)
2,535
(1150)
3’3”
(1.0 m)
2,403*
(1090*)
1,003
(455)
3,120*
(1415*)
1,477
(670)
4,905
(2225*)
2,183
(990)
0’0”
(0.0 m)
2,524*
(1145*)
1,014
(460)
3,428*
(1555*)
1,378
(625)
5,368*
(2435*)
2,028
(920)
-3’3”
(-1.0 m)
2,668*
(1210*)
1,135
(515)
3,329*
(1510*)
1,345
(610)
5,049*
(2290*)
2,017
(915)
8,973*
(4070*)
3,946
(1790)
-6’6”
(-2.0 m)
2,767*
(1255*)
1,554
(705)
3,924*
(1780*)
2,094
(950)
6,614*
(3000*)
4,101
(1860)
Maximum permissible load on standard dipper arm
A Overhang from the center of the turntable
B Height of load fixing point
* Lifting capacity hydraulically limited
Dozer blade support in drive direction
Dozer blade support 90° to drive direction
B
A
