GEIGER GJ56 e Series - Technical Data

10
Gerhard Geiger GmbH & Co. KG | 100W1503 1118V001en
EN
EN
14. Technical data
Technical data GJ56..e with electronic end stop (standard electronic)
GJ5603ke GJ5606ke GJ5610e GJ5618e
Voltage 230 V~/50 Hz
Current 0,40 A 0,40 A 0,60 A 0,80 A
Cos Phi (cosj) > 0,95
Inrush current (factor) x 1,2
Power 90 W 93 W 135 W 180 W
Torque 3 Nm 6 Nm 10 Nm 2 x 9 Nm
Speed 26 rpm
Protection class IP 54
Limit switch range 200 rotations
Operating mode S2 4 min
Sound pressure level
1)
34 db(A) 34 db(A) 35 db(A) 40 db(A)
Length 301 mm 301 mm 311 mm 338 mm
Diameter 55 mm
Weight approx 1,50 kg approx 1,50 kg approx 1,70 kg approx 2,20 kg
Storage temperature/
Humidity
T = -15°C .. +70°C / dry and non-condensing place
Subject to technical modifications. Please find information to the ambient
temperature range of our Geiger motors under www.geiger.de
DE
V
geprüfte
Sicherheit
Technical data GJ56..e with electronic end stop (run-time optimized version)
GJ5606e GJ5616e
Voltage 230 V~/50 Hz
Current 0,40 A 0,70 A
Cos Phi (cosj) > 0,95
Inrush current (factor) x 1,2
Power 90 W 150 W
Torque 6 Nm 2 x 8 Nm
Speed 26 rpm
Protection class IP 54
Limit switch range 200 rotations
Operating mode S2 6 min
Sound pressure level
1)
34 db(A) 40 db(A)
Length 306 mm 338 mm
Diameter 55 mm
Weight approx 1,60 kg approx 2,20 kg
Storage temperature/
Humidity
T = -15°C .. +70°C / dry and non-condensing place
1)
The average sound pressure level data are intended for guidance only. The values were determined by
Geiger at a distance of 1 m, with a hanging motor at idle speed and averaged over 10 seconds. There is
no reference to any specific test standard.
Subject to technical modifications. Please find information to the ambient
temperature range of our Geiger motors under www.geiger.de
