10. Setting of the end stops
I
Motors GF56..e1 – e4: a Geiger setting switch is required for the
setting of the end stops
Motors GF56..e5: the setting can be realized with any switch allowing
simultaneous UP and DOWN commands.
Part-Nr. / Geiger setting switch
M56K144 With Hirschmann STAK3 connector (D)
M56F150 With Hirschmann STAK3 connector (CH)
M56F151 With terminal (D)
M56B265 Adaptation cable with terminal and STAS3
M56E399 Adaptation cable with STAK3 and open cable ends
Readjustment of the end stops
The readjustment of the end stops can be carried out at any time in accordance with the
instructions given below. If there is no running of the blind by the operation points 3, 5 and 7 the
end stops have kept the same position as before.
Shade position/working position (only e1 – e4)
The shade position/working position can be reached by actuating both direction keys at the
same time
Overload recognition
The overload recognition is adapted to the given torque (+ safety margin) of the Venetian blind
system by carrying out the complete adjustment procedure. The blind must be moved by steps
3, 5 and 7.
Setting GJ56..e1, e2 and e3
I
The order of the adjustment process must be strictly adhered to and
the adjustment must always be completely implemented (all steps).
I
The motor GJ56..e3 is set up with a learning mode. During assembly
please begin the setting with step 1 and then go over to step 7.
1. Connect the setting switch to the GJ56..e and then plug in power supply
2. Press the programming button till the LED flashes (1 flash light, break, 1 flash light,
break,…) then release the programming button.
3. Setting of the lower end stop: press the direction keys to exactly run the GJ56..e to the
desired lower end position.
4. Press the programming button till the LED flashes (2 flash lights, break, 2 flash lights,
break,…) then release the programming button
5. Setting of the shade position/working position: press the direction keys to exactly run
the GJ56..e to the desired position.
6. Press the programming button till the LED flashes (3 flash lights, break, 3 flash lights,
break,…) then release the programming button
7. Setting of the upper end position: press the direction keys to exactly run the GJ56..e to
the desired upper end position.
8. Press the programming button till the LED keeps lighting. The adjustment procedure is
completed.
