GEIGER GJ56 e Series - Table of Contents; General Information; Guarantee; Intended Use

2
Gerhard Geiger GmbH & Co. KG | 100W1503 1118V001en
EN
EN
Index
1. General information .................................................................. 2
2. Guarantee ..................................................................................2
3. Intended use .............................................................................. 2
4. Safety instructions ....................................................................3
5. Safety instructions for assembly ............................................3
6. Assembly note ..........................................................................4
7. Installation instructions ...........................................................5
8. Information for the specialist electrician ................................ 6
9. Control features ........................................................................6
10. Setting of the end stops ...........................................................7
11. Operation ...................................................................................9
12. What to do if… ...........................................................................9
13. Maintenance ..............................................................................9
14. Technical data .........................................................................10
15. Declaration of conformity ...................................................... 11
16. Notes on waste disposal ........................................................12
1. General information
Dear customer,
By purchasing a Geiger motor you have decided on a quality product from Geiger.
Thank you very much for your decision and the condence placed in us.
Before you put this drive into operation please observe the following safety instructions. It
serves for the prevention of danger and for the avoidance of personal injury and damage to
property.
The installation and operating instructions contain important information for the installer, the
specialist electrician and the user. Please pass on these instructions if you transfer the product.
These instructions should be kept by the user.
2. Guarantee
In the case of incorrect installation contrary to the installation and operating instructions and/
or constructional modication, the legal and contractual guarantee for property damage and
product liability lapses.
3. Intended use
The motors of the model range GJ56..e with electronic end stop are designed exclusively for
the operation of Venetian blinds.
The motors may not be used for the operation of roller grilles, garage doors, furniture and lifting
tools.
GJ 56 xx x
Design options
Torque in Nm
For head rails at least 56 mm
Geiger Venetian blinds motor
