GEM 1436 cPos User Manual

Travel sensor: Integrated for direct mounting
Linear design Quarter turn
design
Detection range: 0–30 mm 0–50 mm 0–75 mm Angle of rota-
tion
0 - 93°
Operating range: 0–30 mm 0–50 mm 0–75 mm Angle of rota-
tion
0 - 93°
Minimum travel sensor change: ≥ 3 % (only relevant for initialization)
Resistance R: 3 kΩ 5 kΩ 5 kΩ 3 kΩ
Correlation - Travel sensor
1)
spindle/valve position
Retracted (top)
≙ 100% (valve open)
90° ≙ 100%
(valve open)
Extended (bottom)
≙ 0% (valve closed)
0° ≙ 0% (valve
closed)
1) Type of design code 6960: Inversed mode of action compared with description
(Travel sensor signal inversed). For valves with inverted correlation.
8.6 Acoustic data
Noise emission: > 80 dB (A)
8.7 Electrical data
8.7.1 Power supply
Supply voltage: 24 V DC (-5/+10%)
Power consumption:
Order variant
Without fieldbus
(code 000)
Profinet fieldbus
(code PN)
Profibus fieldbus
(code DP)
DeviceNet fieldbus
(code DN)
Single acting: ≤ 4.5 W ≤ 8.6 W ≤ 5.2 W ≤ 4.5 W
Double acting /
Booster:
≤ 6.2 W ≤ 10.7 W ≤ 7.1 W ≤ 6.4 W
plus in each
case:
max. 24 W for act-
ive digital outputs
with max. on-load
current
-
Reverse battery protec-
tion:
Yes
Duty cycle: Continuous duty
Electrical protection
class:
III
8.7.2 Analogue inputs
Set value / actual value: - Set value and actual value input are galvanically isolated from the supply voltage
- Set value and actual value input are not galvanically isolated from the actual value output
- Set value and actual value input are not galvanically isolated from each other
Set value input: 0/4 - 20 mA (adjustable)
Process actual value in-
put:
0/4 - 20 mA (adjustable)
Only for device version code PA01
www.gemu-group.com12 / 76GEMÜ 1436 cPos
8 Technical data
