8 Technical data
8.1 Medium
Working medium: Compressed air and inert gases
Dust content: ≤ 10 mg/m³/particle size ≤ 40 µm (class 7)
Pressure dew point: Class 4, max. pressure dew point +3 °C
Oil content: Class 4, max. oil concentration 5 mg/m³
Quality classes to DIN ISO 8573-1
8.2 Temperature
Ambient temperature: 0 — 60 °C
0 — 50 °C (Profinet code PN)
Storage temperature: 0 — 60 °C
8.3 Product conformity
EMC Directive: 2014/30/EU
Technical standards used:
Interference emission: DIN EN 61000-6-4 (09/2011)
DIN EN 61326-1(industry) (01/2006)
Interference resistance: DIN EN 61000-6-2 (03/2006)
DIN EN 61326-1(industry) (10/2006)
8.4 Pressure
Operating pressure: 1.5 — 7 bar
The applied pressure must not exceed the maximum control pressure of the process valve.
Flow rate:
Flow rate (code) Specification l / min
1)
Specification Nl / min
2)
Code 01 150 l/min 84 Nl/min
Code 02 200 l/min 100 Nl/min
Code 03 (Booster) 300 l/min 172 Nl/min
1) Reference condition: 6 → 0 bar at 25 °C
2) Reference condition: 6 → 5 bar at 25 °C
Air consumption: 0 Nl/min (when idle)
8.5 Mechanical data
Installation position: Optional
Protection class: IP 65 acc. to EN 60529
Weight: 600 g
GEMÜ 1436 cPoswww.gemu-group.com 11 / 76
8 Technical data
