www.gemu-group.com 37 / 76 GEMÜ 1436 cPos
Parameters Value Description Automatic initialization
function
Manual initialization
function4)
Boost NC²⁾³⁾ Control function 1
(closed by spring force)
– with increased con-
troller air output (only
300 l/min)
Control function 1
(closed by spring force)
– with increased con-
troller air output
Control function 1
(closed by spring force)
– with increased con-
troller air output (only
300 l/min)
Boost NO²⁾³⁾ Control function 2
(opened by spring force)
– with increased con-
troller air output (only
300 l/min)
Control function 2
(opened by spring force)
– with increased con-
troller air output
Control function 2
(opened by spring force)
– with increased con-
troller air output (only
300 l/min)
¹⁾The fixed control function setting "DNO" should be used for valves with control function 8 (double acting with opening spring).
When using the "Auto DNO" setting, a deviating control function may be incorrectly detected during an automatic initialization,
and the initialization cannot be completed. The "Wrong Function" error message appears.
²⁾Fixed control functions (NC, NO, DA, Boost NC and Boost NO) must match in terms of the actuator's control function. An incor-
rect assignment may lead to faults and/or inverted action, and should therefore only be used if the correct control function is
known. In case of doubt, give preference to an "auto" detection.
³⁾On versions with 300 l/min flow capability (booster), double the number of pilot valves are installed and connected in parallel.
If, in these versions, a control function is set for simple pilot valves, this leads to a reduction in the flow capability.
⁴⁾A manual initialization should only ever be carried out if you have not achieved satisfactory control characteristics with the
automatic initialization or this was aborted due to an error message.
15 Commissioning
