www.gemu-group.com60 / 76GEMÜ 1436 cPos
16 Operation
16.2.3.8 Menu 4 SetCalibration
W 0% 0.0 % 0.0...100.0 %
SetCalibration 4
Return
Return
Set W-free
X-Direction: rise rise...fall
W-Direction: rise rise...fall
OutMinPos 0.0 % 0.0...100.0 %
W 10% 10.0 % 0.0...100.0 %
W 40% 40.0 % 0.0...100.0 %
W 90% 90.0 % 0.0...100.0 %
W 20% 20.0 % 0.0...100.0 %
W 70% 70.0 % 0.0...100.0 %
W 50% 50.0 % 0.0...100.0 %
W 100% 100.0 % 0.0...100.0 %
W 30% 30.0 % 0.0...100.0 %
W 80% 80.0 % 0.0...100.0 %
W 60% 60.0 % 0.0...100.0 %
OutMaxPos 100.0 % 0.0...100.0 %
W-Function: lin. lin. 1:25 1:50 free
r0w3
r0w3 r0w3
r0w3 r0w3 r0w3 r0w3
r0w3
r0w3
r0w3
r0w3
r0w3
r0w3
r0w3
r0w3
r0w2 r0w2
PotiDir rise rise fall
r0w3
I Max W 20.5 mA 0.0...22.0 mA
I Min W 3.5 mA 0.0...22.0 mA
r3w3 r3w3
I Min X 3.5 mA 0.0...22.0 mA
r3w3
I Max X 20.5 mA 0.0...22.0 mA
r3w3
Return
Decimalpoint 1 0...2
20mA = 100.0 % 0.0...9999
Scaling
4mA = 0% 0.0...9999
r0w3
r0w3
r0w3
r0w3
r0w3
Scaling OFF ON / OFF
r0w3
Y-Direction: rise rise...fall
r0w3
Only available when "W-Function: free"
