Page12
owners manual
Prp700-Prp800
DATA
BALANCE
DATA
BALANCE
DATA
BALANCE
DATA
BALANCE
FUNCTIONS: piano functions menu
Functions Function Lev. 2 Function Lev. 3 parameter range
F1
Temperaments
Equal, Piano 1, Piano 2, Meantone, Kirnberger, Tartini
Vallotti
F2
Global tune - - from 427 to 452 Hz.
F3
Midi In from 1 to 16, common - from 1 to 16 ,off
F4
Midi Out from 1 to 16, common - from 1 to 16 ,off
F5
Midi Local On/Off
F6
Midi In Transpose - - On/Off
F7
Midi Out Filters - - Off(0)/PrgChg(1)/CtrChg(2)/Both(3)
F8
StartUp Mode -. - Factory/User
F9
Midi Dump - - Press data button to start MIDI dump
F10
USB PC mode - - PC1, PC2
F11
Reverb (1) rev type Depth, Time, Predelay
F12
Efx (1) efx type Depth, Par. 1, Par. 2
F13
Equalizer On/Off
F14
Damper Phys. Mod. On/Off
F15
Decay Env. On/Off
F16
Power Led On/Off
The piano functions menu allows you to fi ne adjust the instrument to different operating situations.
F2- Global Tune
This function allows you to fi ne adjust the piano's pitch.
+
-
Press the
Functions button
Pressing the DATA button the display shows the
current tune value (standard pitch A=440 by
default).
Edit the value using
BALANCE DATA
buttons, from 427 to
452 Hz.
F1- Temperaments
This function allows you to select different temperaments
Press Functions
button
Select F1 using SELECT/TEMPO buttons
Pressing the DATA button the display shows the
current temperament value (Equal by default).
Edit the value using
the DATA buttons.
01
Equal
02
Piano 1
03
Piano 2
04
Meantone
05
Kirnberger
06
Tartini
Vallotti
F3- MIDI in
This function allows you to edit the piano MIDI IN confi guration.
Press the Functions
button
Select F3 using the
SELECT/TEMPO
buttons
The Functions
button starts
blinking
Press the
button again
Select a section using
the SELECT TEMPO
buttons
MAIN
LAYER
SPLIT
COMMON
Edit MIDI channel
number using the DATA
buttons
VALUE: From 1 - 16 to OFF
DISPLAY
Select F2 using SELECT/TEMPO buttons
To Next Page
