Gemini PMX-1400 - Page 6

(6)
Parts Lists - PCB1 Input/Output
079-027
079-003
081-027
092-078
161-105
161-106
RECTIFIER DIODE 1N4002 (1N4003,1N4004)
SILICON DIODE 1N4148
SLIDE SWITCH 2P2C PH/LINE
PHONE JACK 6.3
4P RCA JACK P=14mm
6P RCA JACK P=14mm
D3-8, D507, D508
D1, D2
SW1-3
J1
J2-5
J6
Designators Description Part #
Electrical Parts
Item #
1
2
3
4
5
6
076-095
076-104
TRANSISTOR 2SC2878
TRANSISTOR 2SA1048 (2SA1317)
Q2-5
Q1
Designators Description Part #
Transistors
Item #
1
2
074-145
074-107
074-114
INTEGRATED CIRCUIT NJM2068LD
INTEGRATED CIRCUIT NJM7812FA
INTEGRATED CIRCUIT NJM7912FA
IC1-4
IC6
IC7
Designators
Description Part #
ICs
Item #
1
2
3
082-019
082-028
083-069
083-097
072-035
072-107
072-113
071-101
071-159
080-091
080-079
080-080
080-078
LEVER SW 4P2C P=18 PH/LN,LN/LN
ROTARY SWITCH 1-2-5 L=17 FAD ASSIGN
PUSH SWITCH 2P2C L=12.5 CUE,MONO
PUSH SWITCH 4P2C L=12.5
SLIDE VR 45mm L=20 CH VOL MASTER 50KA×2
SLIDE VR 30mm L=15 EQ 20KW C.C
RAILGLIDE VR 45mm X-FADER 100KB×2
ROTARY VR 16f L=20 TREBLE,BASS 10KB C.C
ROTARY VR 16f L=20 MIC LEVEL 10KA
LIGHT EMITTING DIODE (RED)
LIGHT EMITTING DIODE (GREEN)
LIGHT EMITTING DIODE (YELLOW)
LIGHT EMITTING DIODE (RED)
SW4-7
SW9-10
SW11-15
SW8
VR1-4
VR7-13
X-FADER
VR14-15
VR5-6
Red 3.15
Green 2.5x6.5
Yellow 2.5x6.5
Red 2.5x6.5
Designators Description Part #
Electrical Parts
Item #
1
2
3
4
5
6
7
8
9
10
11
12
13
074-104
074-145
074-115
074-022
INTEGRATED CIRCUIT
NJM4558LD(M5218AL,BA4558N)
INTEGRATED CIRCUIT NJM2068LD
INTEGRATED CIRCUIT M5229P
INTEGRATED CIRCUIT LB1403N
IC11
IC8-10
IC12
IC13-16
Designators Description Part #
ICs
Item #
1
2
3
4
074-104
074-113
074-145
074-115
INTEGRATED CIRCUIT
NJM4558LD(M5218AL,BA4558N)
INTEGRATED CIRCUIT NJM4556L
INTEGRATED CIRCUIT NJM2068LD
INTEGRATED CIRCUIT M5229P
IC19, IC20
IC21
IC17
IC18
Designators Description Part #
ICs
Item #
1
2
3
4
080-091LIGHT EMITTING DIODE (RED) 3.15fD35-37
Designators Description Part #
Diodes
Item #
1
083-069
083-097
072-035
072-107
072-092
071-084
060-702
PUSH SWITCH 2P2C L=12.5 CUE,MONO
PUSH SWITCH 4P2C L=12.5 EQ
SLIDE VR 45mm L=20 CH VOL MASTER 50KA×2
SLIDE VR 30mm L=15 EQ 20KW C.C
SLIDE VR 45mm L=20 CUE PGM 20KB×2
ROTARY VR 16f L=20 CUE LEVEL 50KA×2
JUMP WIRE TYPE 0.5f P=5mm T/52mm
SW16
SW17
VR24-25
VR17-23
VR26
VR16
J10
Designators Description Part #
Electrical Parts
Item #
1
2
3
4
5
6
7
Parts Lists - PCB2 Main
Parts Lists - PCB3 Phono
