1.
Unscrew
the outside FADER PLATE SCREWS (B). DO
tauch the INSIDE SCREWS (C).
2. Carefully
lift
the fader and
unplug
the CABLE
(D).
3. Plug
the
new fader into the
cable
and
place
it back in
mixer.
4.
Screw
the fader to the mixer.
0
c
A
c
0
L
I
1’
i,
I
J
D-
BS!.
not
the
5.
PUNCH IN: The PUNCH IN BUTTONS
(14,26)
allow
you to add a
channel’s
Signal
to the mix when the crossfader is set to the opposite
channel.
6.
OUTPUT CONTROL SECTION: The level of the
MASTER OUTPUT (28)
is
controlled
by the MASTER (25) control. The BALANCE (24) control
will
allow
the MASTER OUTPUT
Signal
to be
balanced
between the
left
and right speakers. The BOOTH (23) control adjusts the level of the
BOOTH OUTPUT (29). HINT: The booth OUTPUT is used by some
DJs
to
run
monitor speakers in their DJ booth. You
tan
also use it as a
second
ZONE or AMP output.
NOTE:
The
RECORD
OUT
(30)
has
no
level
control.
The
level
Is
set
by
the
channel
slides
and
the
gain
controls
of
the
selected
channel.
The
tonal
qualities
are
set
by
the
bass,
treble
and
mid
controls
of
that
same
channel.
7. TALKOVER SECTION: The purpose of the talkover
section
is to allow
the
program
playing to be muted so that
the
mit
tan
be heard above
the
music.
The
MIC/TALKOVER
SVVITCH (2) has three
settings.
When
the
MICTTALKOVER
SWITCH (2)
is
in the bottom Position, the
mit
and
talkover are both off. When the
MICITALKOVER
SWITCH
(2) is in the
center
Position
the
mit
is on, the
MIC
INDICATOR (3) will glow, but
talkover is off. When the
MICITALKOVER
SWITCH (2) is in the
top
Position, the
mit
and talkover will be on and the volume of all
sources
except the
Mit
input are lowered by 16
dB.
LEVEL (4) controls the
level of
the
MIC.
8.
CUE SECTION: By connecting a set of headphones to the HEADPHONE
(22)
jack,
you
tan
monitor either channel or both together. Select the
CHANNEL 1 by sliding the CUE SLIDER (16) control to the
left
or
CHANNEL 2 by sliding the CUE SLIDER (16) control to the right. Use
the
CUE LEVEL (5) control to
adjust
the headphone volume without
effecting the
Overall
mix. Use the CUE SPLIT (15) button
to
Split
the
Signals
from
each
channel so that CHANNEL 1 will be heard in one
earphone and CHANNEL 2 will be heard in the other earphone.
9.
DISPLAY: The dual
function
DISPLAY (7) indicates either the MASTER
OUTPUT
(28,31)
left and right levels or the CHANNEL 1 and
CHANNEL 2 input levels. You
tan
choose
the
Option
you
want
by
pressing the DISPLAY (6)
button.
NOTE:
When
the
DISPLAY
(7)
is
in
the
CHANNEL
11
CHANNEL
2
display
mode,
by
adjusting
the
Individual
channel
galn
and
tone
controls,
you
tan
increase
or
decrease
the
slgnal
to
match
the
other
channel’s
Signal.
The
channel
slides
and
crossfader
have
no
effect
on
the
dlsplay
readlngs.
INPUTS:
DJ
Mit
...................................................
.1.5mV
2Kohm
balancec
Phono
......................................
.
.................................
.3mV
47Kohr
Line..
.....................................................................
150
mV
27Kohr
OUTPUTS:
Amp/Booth.
.....................................................
0
dB
1V
4000hr
Max..
...........................
.24V
Peak to
Pea+
Ret
........................................................................... 225mV 5Kohr
GENERAL:
Low (Channels 1
-
2)........................................................
+
12dB/-32
dE
Mid (Channels 1
-
2).........................................................
+
12dB/-32
dE
High (Channels 1
-
2).....................................................
+
12dBI-32
di
Gain (Channels 1
-
2)
........................................................... 0 to
-2od:
Frequency
Response
....................................
2OHz
-
20KHz
+/-
2dE
Distortion
................................................................................
0.02”
S/N
Ratio
...............................................................
better
than
80dt
Talkover Attenuation.
.............................................................
-16di
Headphone Impedance. ........................................................
16ohn
Power Source.. ...........................................
115/23OV
50/60Hz
15\’
Dimensions..
...............
10”~
x
3S”h
x 14”d (254 x 89 x 305
mrr
Weight..
.........................................................................
.6.6
Ibs.
(3
kg
Page 4
